Elvis Nickel Alloys is a premier manufacturer and supplier based in Texas, USA, specializing in high-quality zirconium sheets and plates. With a commitment to excellence, we provide a comprehensive range of products tailored to meet diverse industrial needs, including petrochemical, oil and gas, and chemical processing applications. We are renowned for our exceptional service, cutting-edge technology, and stringent quality control, ensuring that our zirconium sheets and plates offer superior corrosion resistance, durability, and mechanical properties. Our expertise and dedication make us a trusted partner in the industry.
Elvis Nickel Alloys is a reputable manufacturer and supplier of top-notch Zirconium Sheets and Plates based in Texas, USA, with operations extending from Houston to cater to a broad industrial clientele. Committed to precision engineering and a strict adherence to international quality standards, Elvis Nickel Alloys provides Zirconium products that are celebrated for their outstanding durability, resistance to corrosion, and performance even in the harshest conditions. The company specializes in tailored solutions to meet the unique needs of various sectors, ensuring a dependable supply and exceptional service. As a result, Elvis Nickel Alloys is solidifying its status as a go-to source for Zirconium Sheets and Plates throughout the USA and beyond.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Products | Chemical Composition(wt%≤) | ||||||||
| Cd | Co | Cu | Hf | Mg | Mn | Mo | Si | Ti | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60802 (Zr-2) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60804 (Zr-4) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60901 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60904 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.005 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| Products | Chemical Composition (wt%≤) | ||||||||
| U | V | W | C | N | H | O | |||
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60802 (Zr-2) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60804 (Zr-4) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60901 (Zr-2.5Nb) | 0.0035 | – | 0.010 | 0.027 | 0.0080 | 0.0025 | 0.09-0.15 | ||
| R60904 (Zr-2.5Nb) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.01-0.14 | ||
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
The Zirconium Sheets and Plates produced by this Texas-based manufacturer are primarily composed of zirconium, boasting a purity level typically exceeding 99%, with only trace amounts of hafnium and other elements. These sheets and plates are recognized for their remarkable resistance to corrosion in both acidic and alkaline environments. They also demonstrate high ductility, impressive toughness, and tensile strength ranging from 330 to 690 MPa, depending on how they are processed and their condition. With excellent thermal stability and minimal neutron absorption, they are perfectly suited for use in critical and high-performance settings.
Contact us to get a quick quote for your requirement.
The Zirconium Sheets and Plates from this Texas manufacturer are widely utilized across various industries, including nuclear power, chemical processing, aerospace, marine, and medical fields. The material is essential in constructing reactor vessels, heat exchangers, condensers, and chemical processing equipment where corrosion resistance is paramount. Additionally, it finds applications in medical implants and high-precision components due to its biocompatibility and strength. The sheets and plates from Elvis Nickel Alloys enhance the reliability and longevity of equipment operating under extreme conditions, making them a preferred choice in demanding industries.
