Elvis Nickel Alloys, a trusted manufacturer and supplier located in Houston, USA, specializes in top-notch Titanium Grade 5 Coils (Ti-6Al-4V). These coils are designed for high-performance applications in aerospace, marine, and industrial fields. Grade 5 is the most popular titanium alloy, known for its remarkable strength, resistance to corrosion, and lightweight nature. Manufactured to strict standards like ASTM B265 and AMS 4911, these coils come in various widths, thicknesses, and tempers. They’re perfect for use in fabricated components, heat exchangers, and structural parts, offering an excellent mix of workability, toughness, and thermal stability.
Titanium Grade 5 Coil consists of about 90% titanium, 6% aluminum, and 4% vanadium. This alloy boasts impressive mechanical strength, with a tensile strength of around 895 MPa, yield strength of 828 MPa, and elongation of 10–15%. It’s recognized for its high fatigue resistance, thermal stability up to 400°C, and outstanding corrosion resistance, particularly in aerospace and marine settings. Grade 5 is significantly stronger than commercially pure titanium while still being lightweight. Plus, it’s non-magnetic, heat treatable, and suitable for welding, forming, and machining.
|
Titanium Gr 5 Coil Specifications |
||
| Specifications | : | ASTM / ASME SB265 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls |
| Finish | : | 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 5 Coil in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 5 Coil is widely used in applications requiring high strength and corrosion resistance. Its applications include airframes, turbine blades and other aerospace components, due to its light weight and resistance to extreme temperatures in medicine it benefits from its biocompatibility and is used for implant surgery and machinery. In addition, titanium GR 5 coils are used in the medical industry for heat exchangers and pressure vessels, due to their excellent corrosion resistance, especially in harsh environments
