Elvis Nickel Alloys, a reputable manufacturer and supplier located in Houston, USA, proudly offers top-notch Titanium Grade 2 Flanges. These flanges are celebrated for their outstanding corrosion resistance, lightweight nature, and excellent formability. Crafted from commercially pure titanium, Grade 2 flanges are perfect for use in harsh environments where strength and chemical resistance are essential. They come in various styles, including weld neck, blind, slip-on, socket weld, and lap joint, all meeting international standards like ASTM B381 and ASME SB381. You’ll find Titanium Grade 2 flanges widely utilized in industries such as chemical processing, marine, desalination, and aerospace.
Titanium Fasteners come in various grades. Grade 2, which is commercially pure titanium, offers excellent corrosion resistance and moderate strength (around 345 MPa tensile), while Grade 5 (Ti-6Al-4V) boasts high strength (approximately 895 MPa tensile), heat treatability, and superior fatigue resistance. Both grades are non-magnetic, lightweight, and maintain their mechanical integrity across a range of temperatures, from cryogenic to elevated. These fasteners are resistant to corrosion from seawater, chlorides, and strong acids, making them ideal for challenging environments. Their low density, high strength-to-weight ratio, and biocompatibility make them a preferred choice for precision fastening in critical applications.
Specification : ASTM B348 / ASME SB348
Dimension : DIN, ISO, ASTM, JIS, BS, GB, IS and all International Standards
Size Range : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Length : 3 mm to 200 mm
Types : Nuts, Bolts, Screws, Sockets, Studs, Screw, Hex Set Screw, Socket Screw, Cap Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Spring Washers, Studs, Anchors, Marine Anchors, Nut, Hexagon Nut, Hex Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Socket Hexagon Head Screw Anchor Bolt, U- Bolts, J Bolts, Mushroom Head Square Neck Bolts, T-Head Bolts, Wing Screw, Eye Bolt, Foundation Bolts, Structural Bolts.
| Grade | C | N | O | H | Ti | Fe |
|---|---|---|---|---|---|---|
| Ti Gr 2 | 0.10 max | 0.03 max | 0.25 max | 0.015 max | Bal | 0.30 max |
| Ti Gr 5 | 0.10 max | 0.05 max | 0.20 max | 0.015 max | Bal | 0.40 max |
| Tensile strength (min) | 0.2% yield strength (min) | |||
|---|---|---|---|---|
| Designation | MPa | ksi | MPa | ksi |
| Unalloyed grades | ||||
| grade 2 | 340 | 50 | 280 | 40 |
| grade 5 | 920 | 134 | 866 | 126 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium fasteners in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Where strength, corrosion resistance and lightweight materials are important titanium fasteners such as bolts, nuts and screws are required Because of their ability to withstand extreme temperatures and harsh environmental conditions they plays a major role in aerospace, automotive and marine applications Biocompatibility of titanium fasteners in the medical industry. For this reason, invasive surgery is used. In addition, it is used in the pharmaceutical industry, where it is not corrupted by strong chemicals, providing long-term reliability
