Elvis Nickel Alloys stands out as a top manufacturer and supplier of Tantalum Shim in Houston, USA. We specialize in high-purity shims that are renowned for their remarkable corrosion resistance, thermal stability, and biocompatibility. Our tantalum shims are crafted from ultra-pure tantalum, adhering to ASTM B708 and tailored specifications, making them perfect for industries like aerospace, chemical processing, semiconductors, and medical equipment. With exceptional resistance to most acids, particularly hydrofluoric acid, and impressive workability at high temperatures, tantalum is the go-to material for precision applications. At Elvis Nickel Alloys, we provide customized tantalum shims with tight tolerances and consistent surface finishes, catering to high-performance sectors.
Tantalum Shims are crafted from high-purity tantalum (≥99.9%), with strict control over trace elements like oxygen, nitrogen, and carbon to ensure optimal chemical resistance and ductility. Tantalum boasts a melting point of around 3017°C, one of the highest among metals, and a density of 16.6 g/cm³. It delivers a tensile strength of approximately 200–250 MPa, excellent ductility, and can be easily cold-formed. Thanks to its inert nature, tantalum is incredibly resistant to strong acids, including hydrochloric and sulfuric acid, as well as electrochemical corrosion, making it perfect for challenging environments that demand both chemical stability and mechanical reliability.
| Standards : | ASTM / ASME |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Element | R05200 (%,Max) | R05400 (%,Max) |
| C | 0.01 | 0.01 |
| O | 0.015 | 0.03 |
| N | 0.01 | 0.01 |
| H | 0.0015 | 0.0015 |
| Fe | 0.01 | 0.01 |
| Mo | 0.02 | 0.02 |
| Nb | 0.1 | 0.1 |
| Ni | 0.01 | 0.01 |
| Si | 0.005 | 0.005 |
| Ti | 0.01 | 0.01 |
| W | 0.05 | 0.05 |
| Grade | Tensile strength δbpsi (MPa)， ≥ | Yield strength δ0.2， psi (MPa)，≥ | Elongation in 1″/2″ gage length， ％， ≥ |
| RO5200/RO5400 | 30000 (207) | 20000 (138) | 25 |
| RO5252 | 40000 (276) | 28000 (193) | 20 |
| RO5255 | 70000 (481) | 60000 (414) | 15 |
| RO5240 | 40000 (276) | 28000 (193) | 20 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum Shim finds extensive use in chemical process equipment, electronic capacitors, high-temperature furnace components, and semiconductor fabrication, all due to its unparalleled acid resistance and high melting point. In the medical sector, tantalum shims are utilized for implants and radiation shielding, thanks to their biocompatibility and non-reactive characteristics. In electronics, they play a crucial role in thin-film deposition and sputtering applications.
