Elvis Nickel Alloys, a well-regarded manufacturer and supplier located in Houston, USA, specializes in high-purity Tantalum R05240 Sheets and Plates designed for applications that require outstanding corrosion resistance and thermal stability. Crafted in accordance with ASTM B708 standards, these sheets and plates are made from unalloyed tantalum with an impressively low impurity content, guaranteeing consistent quality and performance. Offered in various thicknesses, widths, and custom-cut sizes, Tantalum R05240 finds extensive use in chemical processing, semiconductor manufacturing, aerospace systems, and medical equipment. These products provide dependable service in harsh acid environments and high-temperature settings where contamination is simply not an option.
Tantalum R05240 Sheets and Plates consist of unalloyed tantalum with a minimum purity of 99.95%, featuring only trace amounts of oxygen, nitrogen, carbon, and hydrogen. This material boasts a tensile strength ranging from 240 to 345 MPa, along with excellent ductility and remarkable formability for precise fabrication. Tantalum R05240 retains its mechanical integrity from cryogenic temperatures all the way up to about 3,000 °C (5,432 °F). It exhibits exceptional resistance to hydrochloric, sulfuric, and nitric acids, as well as many other corrosive substances, making it perfect for highly corrosive environments where high purity and stability are crucial.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05240 Sheets and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05240 Sheets are used in demanding applications due to their superior properties. In the electronics industry, they are vital for manufacturing high-performance capacitors and resistors. In chemical processing, these sheets are utilized in equipment handling corrosive substances, such as reactors and heat exchangers. They are also employed in aerospace for components that endure extreme temperatures. Additionally, Tantalum R05240 Sheets are suitable for medical implants and surgical instruments, offering high performance and biocompatibility.
