Home > Super Duplex Steel > Super Duplex Steel S32760 Forged Fittings
Elvis Nickel Alloys, located in Houston, USA, is a well-respected manufacturer and supplier of high-performance Super Duplex Steel S32760 Forged Fittings, crafted for the toughest environments. Made from UNS S32760 (Zeron® 100), these fittings boast impressive mechanical strength, outstanding corrosion resistance, and precise dimensions. Thanks to their unique dual-phase austenitic-ferritic microstructure, they stand up remarkably well against pitting, crevice corrosion, and chloride stress corrosion cracking. With a variety of configurations available, including elbows, tees, couplings, nipples, and unions, these fittings are perfect for critical piping systems and meet global standards like ASTM A182, ASME B16.11, and MSS-SP-79/95.
Super Duplex S32760 Forged Fittings are composed of about 25% chromium, 7% nickel, 3.5% molybdenum, 0.2–0.3% nitrogen, and 0.5–1% copper, along with trace elements like tungsten. These components boost the alloy’s PREN (>40), ensuring it resists localized corrosion in harsh environments. The fittings can handle tensile strength up to 800 MPa and yield strength of at least 550 MPa, while also providing excellent impact toughness, even in freezing temperatures. The forged design enhances grain integrity and mechanical reliability, making them perfect for high-pressure and high-temperature piping systems.
| Specifications | ASTM A182 & ASME SA182 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socketweld Fittings |
| Grades | S32750 / S32760/ S32950 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| Grades | Density (g/cm 3) | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15% |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Cu |
| S32760 | 0.030max | 1.20 max | 0.80 max | 0.035max | 0.020 max | 24.0-26.0 | 3.0-5.0 | 6.0-8.0 | 0.24/0.32 | 0.50 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel S32760 Forged Fittings in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel S32760 Forged Fittings find extensive use in offshore oil and gas platforms, desalination plants, chemical processing facilities, power generation, and marine industries. Their remarkable strength and corrosion resistance make them ideal for connecting pipes in high-pressure, high-temperature, and chloride-rich environments. These fittings play a vital role in assembling pumps, valves, reactors, and heat exchangers, ensuring a leak-proof and durable performance. Their excellent weldability and fatigue strength also make them suitable for subsea applications, refineries, and water treatment plants, providing a long service life and minimizing maintenance needs.
