Elvis Nickel Alloys, located in Houston, USA, is a reputable manufacturer and supplier of top-quality Super Duplex Steel Pipes. These pipes are designed for exceptional strength, corrosion resistance, and a long lifespan, even in the harshest industrial settings. Crafted from advanced materials like UNS S32750 (SAF 2507) and UNS S32760 (Zeron® 100), they feature a unique dual-phase austenitic-ferritic structure that provides outstanding resistance to chloride stress corrosion cracking, pitting, and crevice corrosion. Available in both seamless and welded options, these Super Duplex Steel Pipes comply with international standards such as ASTM A790, ASME SA790, and NACE MR0175, making them perfect for demanding piping applications.
Super Duplex Steel Pipes generally contain 24–26% chromium, 6–8% nickel, 3–5% molybdenum, and 0.2–0.3% nitrogen, along with trace amounts of manganese, copper, and tungsten. These elements contribute to a high PREN (>40), ensuring excellent corrosion resistance. The pipes boast a tensile strength of up to 800 MPa, a yield strength of at least 550 MPa, and remarkable impact toughness, even in freezing temperatures. Their superior mechanical properties and resistance to corrosion make them ideal for high-pressure and high-temperature applications in chemically aggressive and chloride-rich environments.
|
Standard |
: |
ASTM A790 / ASME SA 790 |
|
Type |
: |
Seamless Pipes |
|
Grade |
: |
UNS S32750, UNS 32760 & UNS S32950 |
|
Size |
: |
1/2″NB TO 12 “NB IN |
|
Thickness |
: |
0.5-45mm |
|
Outer Diameter |
: |
6.0-630mm |
|
Dimensions |
: |
OD(6.0-630)*WT(0.5-45)mm |
|
Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80 |
|
Length |
: |
Single Random, Double Random & Cut Length |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
Super Duplex Pipe |
0.030 max |
1.20 max |
0.80 max |
0.035 max |
0.020 max |
24.00 – 26.00 |
3.00 – 5.00 |
6.00 – 8.00 |
0.24 – 0.32 |
|
UNS No |
Grade |
Proof Stress 0.2% (MPa) |
Tensile Strength (MPa) |
Elongation A5(%) |
Hardness Max |
|
|
HB |
HRB |
|||||
|
Super Duplex Steel Pipe |
2507 |
550 |
795 |
15 |
310 |
32* |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Pipe in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Pipes find extensive use in offshore oil and gas platforms, marine systems, chemical processing, desalination plants, power generation, and the pulp and paper industries. Their impressive corrosion resistance and strength make them perfect for seawater handling systems, heat exchangers, pressure vessels, firefighting networks, and process pipelines. These pipes perform reliably in environments exposed to saltwater, acids, and alkaline chemicals, ensuring long-lasting durability with minimal maintenance. Additionally, their high strength-to-weight ratio allows for cost savings in structural design, making them a preferred choice for critical infrastructure and mission-critical applications.
