Elvis Nickel Alloys, a well-respected manufacturer and supplier located in Houston, USA, provides top-notch Super Duplex Steel Coil S32760, crafted for exceptional performance in highly corrosive and high-stress settings. Made from UNS S32760 (Zeron® 100), this coil boasts a well-balanced dual-phase microstructure (austenitic-ferritic), which offers remarkable resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. You can find these coils in a variety of thicknesses, widths, and surface finishes, all meeting global standards like ASTM A240 and EN 10088-2. They’re perfect for use in offshore, chemical processing, marine, and power generation industries.
Super Duplex Steel S32760 Coils are composed of about 24–26% chromium, 6–8% nickel, 3–4.5% molybdenum, 0.2–0.3% nitrogen, and 0.5–1% copper, along with trace amounts of tungsten and manganese. This unique blend results in a PREN (Pitting Resistance Equivalent Number) greater than 40, ensuring outstanding corrosion resistance. The coil can achieve tensile strength up to 800 MPa and yield strength of at least 550 MPa, along with excellent impact resistance even in low temperatures. Its remarkable mechanical properties and corrosion resistance make it ideal for demanding structural and pressure-containing applications.
|
Standard |
ASTM A240 / ASME SA240 |
|
Thickness |
0.2mm – 5.0mm |
|
Width |
3.2mm – 1500mm |
|
Length |
AS PER CUSTOMER’S REQUIREMENT |
|
Test Certificate |
Yes |
|
Coils Hardness |
Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
|
Finish |
Hot rolled Coils (HR), Cold rolled Coils (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
|
Form |
Coil / Strip |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Super Duplex Steel Coils | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| Super Duplex Steel Coils | 7.8 | 0.281 | 1350 | 2460 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Coils S32760 in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Coil S32760 is used in high-strength applications and requires corrosion resistance, especially in harsh environments. They are ideal for offshore oil and gas installations, where they can withstand harsh marine conditions and high pressures. These coils are also used in chemical plants for handling strong chemicals and in desalination plants for seawater resistance, used in electrical and marine industries to ensure it performs reliably and for a long time in complex applications requiring complex components
