Elvis Nickel Alloys is a top manufacturer and supplier of high-performance nickel-based alloys located in Houston, USA. Among its premium products are Rene 41 Sheets and Plates, designed for strength and heat resistance. These superalloy items meet the demanding needs of the aerospace, defense, and high-temperature industrial sectors. They perform well in environments over 1,800°F. Elvis Nickel Alloys provides Rene 41 materials with precise machining and quality control to ensure strong structural integrity and reliability. The company emphasizes technical quality and customer satisfaction, offering solutions for even the toughest applications.
Rene 41 Sheets and Plates consist of a nickel-chromium-based superalloy that contains about 19% chromium, 11% cobalt, 10% molybdenum, and small amounts of aluminum and titanium for added strength. This alloy maintains high strength and oxidation resistance at temperatures up to 1,800°F (980°C). Typical tensile strength is over 1,200 MPa, along with excellent creep and stress rupture resistance. Rene 41 can be age-hardened and shows good fatigue and thermal stability. Its mechanical strength and stability make it suitable for extreme environments where both mechanical and thermal stresses are high.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates are commonly used in applications that require excellent high-temperature strength and oxidation resistance. These applications include aerospace components like turbine engine parts, afterburner assemblies, and exhaust ducts. They are also used in missile systems, nuclear reactors, and other defense technologies where performance under heat and pressure is essential. In industrial sectors, Rene 41 is used for high-temperature tooling, combustion chambers, and structural components that face cyclic thermal stresses. Its ability to maintain mechanical properties under prolonged exposure to harsh conditions makes it ideal for critical environments across engineering fields.
