Home > Rene 41 Foil
Elvis Nickel Alloys, a reputable manufacturer and supplier located in Houston, USA, proudly offers top-notch Rene 41 Foil. This age-hardenable, nickel-based superalloy is specifically engineered for high-temperature and high-stress applications in aerospace and industry. With its remarkable strength at elevated temperatures reaching up to 1600°F (870°C), Rene 41 Foil ensures structural stability and corrosion resistance even in the most extreme conditions. Crafted in ultra-thin gauges with precise tolerances, it’s perfect for projects that demand high-performance and lightweight materials. The foil meets essential standards like AMS 5545 and AMS 5712, making it a go-to choice for turbine engines, exhaust systems, and heat shielding components.
Rene 41 Foil is mainly made up of Ni (Balance), featuring around 19% Cr, 11% Co, 10% Mo, and 3% Ti, along with Al, Fe, and trace elements. This careful alloying process grants it high-temperature strength through gamma prime precipitation hardening. It boasts a tensile strength greater than 150 ksi (1030 MPa) and excellent creep resistance at temperatures up to 1600°F. The foil also shows good oxidation resistance, maintaining its integrity during thermal cycling. With its impressive mechanical performance and thin, formable nature, Rene 41 is perfect for high-stress aerospace and thermal protection systems.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Rene 41 foil is a high-strength and heat-resistant adhesive used in complex applications. It is mainly used in the aerospace industry for components subjected to extreme conditions, such as gas turbine engines, rocket motors and exhaust systems and its excellent resistance to oxidation, corrosion and creep makes it ideal for applications high quality, especially turbine blades , Rene foil electricity in the manufacture of rings and seals It finds applications in manufacturing, military equipment and advanced technology long-term areas under stress and high temperatures are more important.
