Elvis Nickel Alloys is a reliable manufacturer and supplier of Nitinol Superelastic Tubes, catering to clients from Houston, USA, and worldwide. These tubes are designed specifically for high-performance applications requiring superior elasticity and deformation recovery. Utilized widely in the medical device industry, the superelastic tubes manufactured by Elvis Nickel Alloys are built to tight tolerances and surface finishes. The company marries sophisticated manufacturing processes with metallurgical expertise to provide tubes that function consistently well in dynamic conditions, providing unparalleled resilience and accuracy for sophisticated engineering systems.
Nitinol Superelastic Tubes are made of a Nickel-Titanium alloy containing around 55.8% Nickel and the rest as Titanium. The tubes are in austenitic condition at room temperature and transform into martensite under stress, providing up to 8% recoverable strain. They have tensile strengths ranging from 895 MPa to 965 MPa, with exceptional fatigue resistance and kink resistance. Superelastic tubes sustain superior performance across multiple mechanical cycles and provide superior corrosion resistance in physiological fluids. The transition temperature can be tailored to meet application-specific demands, providing functional flexibility.
| Standards : | ASTM F2063 / ASME SF2063 |
| Wall Thickness : | 0.05 mm-3mm |
| Outer Diameter : | 0.70mm~3.00mm |
| Property: | Shape Memory Alloy |
| Condition : | Annealing |
| Af range : | -5 to 40 ℃ |
| Length range : | 500-1800mm |
| Wall Thickness Range : | 0.05 mm-3mm |
| Grade | Ni | C | Co | Cu | Cr | H | Fe | Nb | N | O | Ti |
| Nitinol | 55.6 | 0.037 | 0.004 | 0.005 | 0.002 | 0.002 | 0.012 | 0.005 | 0.005 | 0.035 | Balance |
| Element | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) |
| Nitinol Tube | 1450 | 445 | 17 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| STANDARD | UNS | ASTM |
| NiTi Alloys | N01555 | ASTM F2063 |
Nitinol Superelastic Tubes have various applications in medical devices like stents, catheter supports, and orthopedic implants because of their elasticity, fatigue strength, and biocompatibility. In robotics and industrial automation, they are best suited for parts that are subject to recurrent bending and dynamic loading. The fact that they can be deformed a great deal and return automatically to their original configuration renders them indispensable in applications where other metals cannot be used, enhancing reliability and durability in critical, high-performance applications.
