Elvis Nickel Alloys produces and supplies high-quality Nitinol Shape Memory Sheets and Plates from Houston, USA. These sheets and plates are designed for smart applications needing accurate thermal activation and revert to a specified shape upon heating. With precise composition control and sophisticated processing, these materials provide excellent fatigue life, reproducible transformation behavior, and high strength. Elvis Nickel Alloys produces Nitinol plates and sheets to meet strict tolerances, making them perfectly suited for incorporation into systems where the usage of common materials cannot present adaptive or temperature-sensitive functionality.
Nitinol Shape Memory Plates and Sheets consist of about 55% Nickel and 45% Titanium. These materials are tailored for the shape memory effect, in which they can be deformed at low temperatures and revert to their original shape upon heating above the austenitic transformation temperature. The tensile strength is between 800 and 965 MPa, and the material can withstand up to 6–8% strain. Transformation temperatures are adjustable through heat treatment. These plates and sheets also provide corrosion resistance, fatigue strength, and superior dimensional stability in thermal cycling.
| Standards : | ASTM F2063 / ASME SF2063 |
| Material : | Nickel: 54.5-57 wt%, Balance: Ti |
| Nitinol Plate Sizes : | 0.004”-0.2” x W x L |
| Nitinol Sheet Thickness : | 0.003” (0.076mm) to 0.098” (2.5mm) |
| Nitinol Sheet Width : | up to 3.5” (90mm) with larger sizes upon request |
| Nitinol Sheet Length : | up to 20” (500mm) |
| Alloys : | Shape Memory |
| Surface : | Natural Oxide, Pickled/Etched and Customer Specific Requirements |
| Thermomechanical Conditions : | As Cold-Worked, Straight Strain Annealed and Shape Set Annealed. |
| STANDARD | UNS |
| NiTi Alloys | N01555 |
| Grade | Ni | N+O | Fe | Co | C | Nb | Cr | Cu | H | Ti |
| Nitinol | 54.5 – 57.0 | 0.050 | 0.050 | 0.050 | 0.050 | 0.025 | 0.010 | 0.010 | 0.005 | Bal |
| Element | Density | Melting Point | Elongation |
| Nickel-titanium Alloy | 6.45 g/cm3 – 0.234 lb/in3 | Around 1310 °C. | 10 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nitinol Shape Memory Sheets and Plates are utilized in smart structures, thermal actuators, and deployable mechanisms. They are used in the biomedical applications for implants and surgical instruments that need shape recovery due to body temperature. They are employed by aerospace engineers for adaptive fasteners and morphing surfaces, enhancing aerodynamic efficiency. They find applications in consumer electronics and robotics for shape–changing or self–folding components. Their ability to “remember” and revert to a pre-defined form when heated provides novel design capabilities, and thus they are crucial in the next-generation smart devices and systems that need adaptive functionality.
