Based in Houston, Texas, Elvis Nickel Alloys is a top producer and supplier of Nimonic 90 Sheets and Plates. Delivering premium nickel-chromium-cobalt alloys made for high-performance settings is our area of expertise. Our Nimonic 90 products are designed to satisfy the demanding requirements of industrial, power generation, and aerospace applications. They are renowned for their exceptional strength, oxidation resistance, and heat tolerance. At Elvis Nickel Alloys, prompt delivery, accuracy, and quality are our top priorities. Our Nimonic 90 sheets and plates, supported by sophisticated manufacturing processes and in-depth metallurgical knowledge, offer reliable performance and durability for both standard and custom orders.
About 57% nickel, 20% chromium, and 18% cobalt make up Nimonic 90 Sheets and Plates, with titanium and aluminium added for reinforcement. Excellent mechanical qualities are provided by this precipitation-hardened alloy, which has a yield strength of about 650 MPa and a tensile strength of up to 1000 MPa. Up to 920°C, it maintains its strength and resistance to corrosion. Nimonic 90 is a dependable solution in settings where mechanical and thermal stability are crucial because of its strong creep and fatigue resistance, making it perfect for high-stress, high-heat applications.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In high-temperature, high-stress settings, Nimonic 90 Sheets and Plates are frequently utilised. They are necessary for the production of jet engine exhaust systems, combustion chambers, and turbine blades in the aerospace sector. Because of their remarkable resistance to heat and oxidation, they are used in nuclear reactors, heat exchangers, and gas turbines in the power generation industry. High-performance exhaust systems and turbocharger components are examples of automotive applications. High-pressure vessels, valves, and furnaces are all used in industry. Nimonic 90 is a dependable material for demanding engineering and thermal applications because of its exceptional creep resistance and mechanical strength at high temperatures.
