Based in Houston, USA, Elvis Nickel Alloys is a top producer and supplier of nickel alloy pipe fittings, offering dependable and corrosion-resistant solutions for high-performance piping systems. All of our pipe fittings, such as elbows, tees, reducers, caps, and couplings, are made from high-quality nickel-based alloys that offer remarkable durability in the face of extreme pressure, temperature, and corrosion. To satisfy the unique requirements of sectors like oil and gas, chemical processing, power generation, marine, and aerospace, we provide fittings in a range of sizes, schedules, and grades. Our top priorities at Elvis Nickel Alloys are accuracy, excellence, and client satisfaction.
High-performance alloys like Inconel, Monel, Hastelloy, and Alloy 600/625/825 are used in the production of nickel alloy pipe fittings. In order to improve mechanical strength and corrosion resistance, these materials usually contain 50–70% nickel along with elements like chromium, molybdenum, copper, and iron. They have outstanding resistance to oxidation, stress-corrosion cracking, and high-temperature creep, and their tensile strengths range from 700 to 1100 MPa. Better grain structure and mechanical integrity are provided by their forged or wrought construction, which qualifies them for high-pressure operations, thermal cycling, and harsh chemical environments in a variety of crucial applications.
| Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Nickel Alloy Pipe Fittings size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Nickel Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Grade Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 Buttweld Fitting |
| ASTM B366 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Nickel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| – | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| Nickel 200 | 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – |
| Nickel 201 | Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy Pipe Fittings in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy of Nickel In industries where dependability, safety, and resistance to corrosion and high temperatures are critical, pipe fittings are indispensable. They are employed in oil and gas operations to handle corrosive fluids and sour gas in pipelines, refineries, and offshore platforms. They are essential for high-temperature systems, acid processing, and reactors in chemical and petrochemical facilities. They are used in nuclear systems, boilers, and condensers in power plants. Because of their resistance to salt, marine industries use them in seawater systems. These fittings are also used in the aerospace, defence, and pharmaceutical industries, where strength and integrity are essential in harsh operating environments.
