Elvis Nickel Alloys, a prominent manufacturer and supplier located in Houston, USA, specializes in high-quality Nickel Alloy Bars designed to excel in extreme conditions involving heat, corrosion, and mechanical stress. Crafted from premium alloys like Inconel®, Monel®, Hastelloy®, Nickel 200/201, and Alloy 20, these bars come in various shapes—round, hex, square, and flat—to cater to a wide range of industrial needs. Engineered with precision to comply with standards such as ASTM B160, B164, and B574, these bars are vital in sectors like aerospace, chemical processing, marine, power generation, and oil & gas, where durability and resistance to corrosion are paramount.
Nickel Alloy Bars generally consist of nickel (up to 99%) as the primary element, combined with other elements like chromium, molybdenum, iron, copper, and cobalt, depending on the specific grade. This unique blend provides impressive tensile strength (ranging from 450 MPa to over 1000 MPa), outstanding yield strength, and elongation capabilities, along with exceptional resistance to oxidation, chloride stress corrosion, and creep at high temperatures. Additionally, nickel alloys offer good thermal stability, weldability, and non-magnetic characteristics, making them dependable for applications that demand a long service life in challenging environments.
| Nickel Bar Standard | ASTM B160, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Nickel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Nickel Round bar size | Diameter: 3-~800mm |
| Nickel Hex Bar size | 2-100mm A/F |
| Nickel Alloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nickel Square bar size | 4 to 100mm |
| Alloy Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Nickel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM B160 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nickel Alloy Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Nickel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Alloy Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| ASTM B160 Type Hollow Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Grade | Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Nickel Alloy | 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| Nickel Alloy | 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy Bars in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel alloy bars are widely used in aerospace for their high strength and resistance to extreme temperatures. In the marine industry, they provide excellent corrosion resistance, making them ideal for components exposed to seawater. They are also crucial in chemical processing for their ability to withstand aggressive environments. Additionally, nickel alloy bars are used in power generation and oil and gas sectors for their durability under high stress and harsh conditions. Their versatility makes them essential in various industrial applications.
