Based in Houston, Texas, Elvis Nickel Alloys is a leading producer and supplier of Nickel Alloy 201 Coil, which is intended for use in harsh industrial settings requiring exceptional thermal stability and corrosion resistance. Our coils are perfect for high-temperature applications and chemically aggressive environments because they are made from low-carbon commercially pure nickel (UNS N02201). These coils, which come in a range of widths, thicknesses, and finishes, are expertly processed to satisfy international quality standards. Elvis Nickel Alloys provides reliable coil solutions that guarantee consistent performance, long service life, and excellent formability, whether for heat exchangers, electrical components, or chemical processing systems.
With a low carbon content (maximum 0.02%) and at least 99.5% nickel, Nickel Alloy 201 Coil has improved resistance to graphitisation at high temperatures. It has outstanding mechanical qualities, such as a high elongation of about 45%, a yield strength of about 148 MPa, and a tensile strength of about 403 MPa. Additionally, the alloy offers exceptional resistance to reducing agents and caustic alkalis. Nickel 201 is perfect for forming and welding because of its exceptional ductility, electrical conductivity, and thermal conductivity. Because of these characteristics, the coil can be used in highly corrosive and thermally active environments.
|
Standard |
ASTM B162 / ASME SB162 |
|
Thickness |
0.2mm – 5.0mm |
|
Width |
3.2mm – 1500mm |
|
Length |
AS PER CUSTOMER’S REQUIREMENT |
|
Test Certificate |
Yes |
|
Coils Hardness |
Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
|
Value Added Services |
Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
|
Form |
Coil / Strip |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel Alloy | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel Alloy | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 201 Coil in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Numerous industries, including chemical processing, electronics, marine, aerospace, and food handling, use Nickel Alloy 201 Coil from Elvis Nickel Alloys. It is particularly useful for lining reactors, heat exchangers, and equipment that handle corrosive chemicals like hydrochloric acid and caustic soda. Because of its high electrical conductivity, it can be used in conductive strips, circuit components, and battery terminals. Long-lasting performance in conditions involving heat, moisture, and chemical exposure is guaranteed by the coil’s exceptional formability and corrosion resistance. Nickel 201 Coil is a popular option for fabrication and manufacturing processes needing chemical integrity and strength because of its purity and robustness.
