Located in Houston, USA, Elvis Nickel Alloys is a well-known manufacturer and supplier that specialises in premium Nickel Alloy 201 Bars that are made to withstand the harsh requirements of high-temperature and industrial settings. Commercially pure nickel (UNS N02201), which is used to make these bars, has a remarkable resistance to corrosion, particularly in reducing and caustic environments. Our Nickel 201 bars provide outstanding machinability, weldability, and formability and come in a range of sizes, shapes, and finishes. Elvis Nickel Alloys guarantees dependable performance for crucial applications in the chemical processing, power generation, and marine sectors thanks to stringent quality assurance and prompt delivery.
With a maximum carbon content of 0.02% and a minimum of 99.5% pure nickel, Nickel Alloy 201 Bars reduce the possibility of graphitisation under high-temperature circumstances. These bars offer a tensile strength of approximately 403 MPa and a yield strength around 148 MPa, with elongation typically at 45%, reflecting excellent ductility and toughness. The alloy provides exceptional corrosion resistance in alkaline, neutral, and reducing environments while remaining stable under thermal cycling. It is ideal for precision machining and fabrication in a variety of industrial applications due to its exceptional electrical and thermal conductivity.
| Nickel Bar Standard | ASTM B160, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Nickel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Nickel Round bar size | Diameter: 3-~800mm |
| Nickel Hex Bar size | 2-100mm A/F |
| Nickel Alloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nickel Square bar size | 4 to 100mm |
| Alloy Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Nickel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM B160 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nickel Alloy Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Nickel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Alloy Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Grade | Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Nickel 201 | 99.0 min | 0.4 max | 0.02 max | 0.35 max | 0.2 max | 0.25 max | 0.15 max | 0.1 max | 0.01 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 201 Bars in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Bars of Nickel Alloy 201 from Elvis In chemical processing equipment, nickel alloys are widely used, especially in heat exchangers, storage tanks, reactors, and caustic handling systems. They are perfect for use in battery manufacturing, electronic components, marine hardware, and food processing because of their exceptional resistance to corrosive media. Because of their high purity and thermal stability, these bars are also used in the pharmaceutical, power generation, and aerospace industries. Nickel 201 bars are dependable in settings requiring high mechanical strength, resistance to corrosion, and resistance to harsh chemicals and high temperatures due to their exceptional machinability and formability.
