Elvis Nickel Alloys is a leading Houston, USA-based supplier and manufacturer of Nickel Alloy 200 Pipe Fittings that specializes in providing reliable, high-performance nickel-based solutions. Our pipe fittings are made from high-purity Nickel 200 with high resistance to corrosive environments and mechanical stress. Engineered to satisfy the tough requirements of customers like chemical processing, marine, and power generation industries, these fittings provide safe and leak-free connections under harsh environments. At Elvis Nickel Alloys, we take pride in excellent workmanship, quick turnaround, and quality service that caters to domestic as well as overseas markets with precision-engineered solutions.
Nickel Alloy 200 Pipe Fittings consist of commercially pure nickel (≥99.6%) with extremely low carbon (≤0.15%), along with trace levels of elements such as iron, copper, and manganese. The above composition provides superior resistance to corrosive chemicals and high-temperature conditions. The tensile strength of the alloy is about 380 MPa, yield strength is about 100 MPa, and elongation is about 45%. It shows superior ductility, thermal conductivity, and magnetic properties. Nickel 200‘s purity also enables it to function reliably in caustic alkalis and reducing chemicals‘ conditions without embrittlement or structural deterioration.
| Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Nickel Alloy Pipe Fittings size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Nickel Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Grade Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 Buttweld Fitting |
| ASTM B366 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Nickel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| – | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| Nickel 200 | 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – |
| Nickel 201 | Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Pipe Fittings in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 Pipe Fittings have extensive application in industries requiring resistance and durability against corrosive conditions. Some of the major applications are in chemical processing plants, power generation plants, petrochemical refineries, and marine applications. The fittings are best suited for the treatment of caustic solutions, acid media, and high-temperature fluids in piping systems. They are also ideally used in electronic and aerospace components due to their non-magnetic and high-conductivity characteristics. Nickel 200 pipe fittings are typically used in reactors, heat exchangers, condensers, and storage tanks, providing long life and mechanical integrity even in severe pressure and thermal cycling environments.
