Elvis Nickel Alloys is a well-known producer and distributor of high-strength Nickel Alloy 200 Flanges in Houston, USA. Our flanges are designed with commercially pure Nickel 200, which boasts good corrosion resistance, thermal stability, and mechanical strength. Our flanges are made to provide effective sealing and connection in piping systems in diverse demanding industries. Whether for marine, power generation, or chemical processing applications, Elvis Nickel Alloys supplies precision-engineered, long-lasting flanges according to international specifications. With competitive pricing, timely delivery, and technical support, we are your reliable business partner for high-quality nickel alloy flange solutions
Nickel Alloy 200 Flanges consist of commercially pure nickel (≥99.6%), low carbon content (≤0.15%), and traces of iron, manganese, copper, and silicon. It offers superior resistance to reducing chemicals and caustic alkalis. Its tensile strength is approximately 380 MPa, yield strength is 100 MPa, and elongation is about 45%, demonstrating superior toughness and ductility. Nickel 200 flanges also have outstanding thermal and electrical conductivity, low magnetic permeability, and are suited for high-performance usage in corrosive and high-temperature conditions.
| Dimensions | ASTM B564 / B182 |
| Grades | 200 (N02200), 201 (N02201), Alloy 20 (N08020). |
| Size | 1/8″ NB TO 48″ NB. |
| Class | 150#, 300#, 400#, 600#, 900#, 1500#, 2500#, 3000#. Also as per the National & International Standard. |
| Standard | SORF, SOFF, SOLJ, SWFF, WNRF, WNFF, WNRTJ, LWNRF, BLRF, BLFF, BLRTJ, SWRF, LAP Joint, Threaded, Reducing, Spectacle, Orifice & Studding Outlet are manufactured according to ANSI B 16.5, B 16.47 Series A (MSS SP-44), B 16.47 Series B (API 605), MSS SP-43, DIN 2527, DIN 2566, DIN 2576, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2642, BS 10, IS 1538 & IS 6392, etc |
| Types of Flanges | Weld neck Flanges (WNRF), Slip-on Flanges (SORF), Blind Flanges (BLRF), Lap Joint Flanges, (SOLJ), Socket-weld Flanges (SWRF), Screwed (Threaded) Flanges, Long weld neck Flanges (LWNRF), Spectacle Blind Flanges, Spacer & Blind Flanges, Ring Type Joint Flanges (RTJ), Reducing Flanges, Raised Face (RF) Flanges, Orifice Flanges, Deck Flange, Large Diameter Flanges, Custom Flanges, Drawing Flanges, Forged Flanges, Plate Flanges, Flat Face Flanges, etc. |
| Form | Slip-On Flange (SO), Blind Flange (BL), Lap Joint Flange (LF), Socketweld Flange (SW), Weld Neck Flange (WN), Long Weld Neck Flange (LWN), Ring Type Joint (RTJ), Threaded Flange, Customized Flange with Raised Face (RF), Flat Face (FF). |
| Grade | Ni | Fe | C | Mn | Si | Cu | Ti | S |
| Nickel 200 | 99.0 min | 0.4 max | 0.15 max | 0.35 max | 0.1 max | 0.25 max | – | 0.01 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Flanges in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 Flanges find extensive use across industries that demand hard, corrosion-resistant connections for piping systems. Typical usage is chemical processing, petrochemical, marine, power generation, and food processing. The flanges are best suited for systems carrying caustic solutions, acidic compounds, and high-temperature fluids. Excellent thermal conductivity and chloride stress corrosion cracking resistance make the flanges suitable for heat exchangers, condensers, and pressure vessels. Nickel 200 flanges are also used in aerospace and electronics due to their conductivity and purity. Their corrosion resistance, strength, and reliability make them a fundamental part in high-performance environments.
