Elvis Nickel Alloys is a renowned manufacturer and stockist of Nickel Alloy 200 Bars in Houston, USA. We offer high-quality bars manufactured from commercially pure nickel to provide excellent mechanical properties and superior resistance to corrosive conditions. Our Nickel 200 bars are made available in a range of sizes and specifications, ideal for demanding applications in chemical processing, marine, aerospace, and electrical fields. With emphasis placed on performance, precision, and customer satisfaction, Elvis Nickel Alloys provides consistent products of good quality that conform to international standards and cater to various industrial applications with timely delivery and consistent quality.
Nickel Alloy 200 Bars are made of commercially pure nickel (≥99.6%) with extremely low carbon levels (≤0.15%) and trace amounts of iron, copper, manganese, and silicon. This makes the alloy more resistant to alkalis and reducing agents. The bars have great mechanical properties, such as tensile strength of about 380 MPa, yield strength of 100 MPa, and elongation of about 45%. Nickel 200 also exhibits excellent ductility, thermal conductivity, and electrical conductivity, as well as minimal magnetic permeability, ideal for structural and functional uses in harsh industrial applications.
| Nickel Bar Standard | ASTM B160, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Nickel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Nickel Round bar size | Diameter: 3-~800mm |
| Nickel Hex Bar size | 2-100mm A/F |
| Nickel Alloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nickel Square bar size | 4 to 100mm |
| Alloy Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Nickel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM B160 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nickel Alloy Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Nickel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Alloy Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Bars in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 Bars find applications in a broad variety of industries where resistance to corrosive and high-temperature conditions is essential. Common uses are in chemical and food processing equipment, marine parts, electronic connectors, aerospace components, and power generation equipment. They are well suited for the manufacturing of components like fasteners, shafts, pump components, and heat exchanger components. Their superior electrical conductivity also makes them qualified for use in battery terminals and electronic components. Nickel 200 bars also exhibit excellent performance in the caustic alkali environment and are thus a choice for reactors, piping components, and structural components in aggressive industrial applications.
