Houston, USA-based Elvis Nickel Alloys is a manufacturer and provider of top-grade nickel alloy items, such as high-performance Monel Washers. Engineered to provide outstanding durability and corrosion resistance, our Monel Washers are the best choice for high-stakes fastening processes in demanding conditions. With fine craftsmanship and stringent quality assurance, we deliver washers to international standards and customer–defined specifications. Supplying markets like marine, chemical processing, aerospace, and oil & gas, Elvis Nickel Alloys has established a name for dependability, timely delivery, and unequalled product performance in the industry of nickel alloy parts.
Monel Washers are basically composed of Monel 400, a nickel-copper alloy with about 67% nickel and 30% copper, with minor content of iron, manganese, carbon, and silicon. This composition offers excellent resistance to seawater, acids, and alkalis. Mechanically, Monel Washers have tensile strength of 70–85 ksi (480–590 MPa), yield strength of 25–35 ksi (170–240 MPa), and elongation rate of approximately 30%. The washers sustain structural stability under conditions of high pressure and temperature, offering superior mechanical performance and long-term durability in corrosive and high-stress industrial environments.
| Monel Washers Standard | ASTM B164 / ASME SB164 |
| Monel Washer Dimensions | ASTM, DIN, BS, GB, IS and all International Standards |
| Monel Washers Size Range | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Monel Alloy Washers Length | 3 mm to 200 mm |
| SA 164 Monel Washers Marking | All Fasterners are marked as follows: Grade, Standard, Thickness, Heat No. (Or according to the customer’s request.) |
| Delivery Time | 7-15 working days as usual, It will based on the detailed order quantity. |
| Payment Terms | Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping |
| Element | Content (%) |
| Nickel, Ni | 63.00 min |
| Silicon, Si | 0.5 max |
| Carbon, C | 0.3 max |
| Sulphur, S | 0.024 |
| Copper, Cu | 28-34 |
| Iron, Fe | 2.5 max |
| Manganese, Mn | 2 max |
| Properties | Metric | Imperial |
| Tensile strength(annealed) | 517-620 MPa | 75-90 ksi |
| Yield strength | 172-345 MPa | 25-50 ksi |
| Modulus of elasticity | 179 GPa | 26000 ksi |
| Poisson’s ratio | 0.32 | 0.32 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Washers in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Washers are extensively used wherever there is a need for excellent corrosion resistance and strength. In marine engineering, Monel Washers are a necessary component for fastening items that are exposed to seawater, like flanges and valves. Monel Washers in the chemical and petrochemical sectors find application in reactors, heat exchangers, and piping systems to resist corrosive chemicals. They are also critical in oil & gas exploration machinery, offshore rigs, and aerospace assemblies where reliability at critical environments is paramount. Their non-magnetic and high-strength features make them ideal for application in sensitive electrical and nuclear environments to provide long-term performance and safety.
