Elvis Nickel Alloys is a reputable Monel Pipe manufacturer and supplier in Houston, Texas, offering top-notch piping solutions to businesses that operate in harsh and corrosive environments. Our Monel pipes, which come in grades 400 and K500, are renowned for their remarkable resistance to high temperatures, acids, alkalis, and seawater. These pipes are widely used in the chemical, oil and gas, and marine industries because of their long service life and durability. Elvis Nickel Alloys provides Monel piping products that satisfy project-specific specifications and international standards with a strong dedication to quality, prompt delivery, and customer satisfaction.
Monel 400 or K500 alloys, which are mainly composed of about 63% nickel and 28–34% copper with trace amounts of iron, manganese, silicon, and carbon, are used to make Monel pipes. With a tensile strength of 480–620 MPa and a yield strength of 170–345 MPa, Monel 400 offers exceptional mechanical strength and resistance to corrosion. Precipitation hardening gives Monel K500, which has been enhanced with titanium and aluminium, more strength and hardness. Monel pipes are perfect for harsh conditions and high-performance applications because both alloys retain exceptional ductility, thermal conductivity, and structural integrity over a broad temperature range.
|
Dimensions |
: |
ASTM, ASME and API |
|
Grade |
: |
Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500) |
|
Monel Seamless Pipes |
: |
ASTM B165, ASME SB165 |
|
Monel Welded Pipes |
: |
ASTM B725 / ASME SB725 |
|
Size |
: |
1/8″NB TO 30″NB IN |
|
Specialized in |
: |
Large Diameter Size |
|
Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
|
Form |
: |
Round, Hydraulic Etc |
|
Type |
: |
Seamless / ERW / EFW / Welded / Fabricated / CDw |
|
Length |
: |
Single Random, Double Random & Cut Length. |
|
End |
: |
Plain End, Beveled End, Threaded |
| C | Mn | Si | S | Cu | Fe | Ni | Cr | |
| Monel | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Monel | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Pipes in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel pipes are extensively utilised in sectors where mechanical dependability and resistance to corrosion are critical. These consist of power generation systems, chemical processing facilities, offshore oil and gas platforms, and marine and shipbuilding applications. They work especially well for moving aggressive fluids like brine, seawater, acids, and alkalis. In applications where longevity and leak-proof performance are essential, such as heat exchangers, condensers, distillation columns, and pressure vessels, monel pipes are used. They are also appropriate for delicate settings like nuclear power plants, aerospace, and defence applications due to their non-magnetic nature and strong resistance to stress corrosion cracking.
