Elvis Nickel Alloys, a leading manufacturer and supplier based in Texas, USA, specializes in providing high-quality Monel Forged Fittings. Renowned for their durability and resistance to corrosion, these fittings are essential in industries requiring robust performance under extreme conditions. Our Monel Forged Fittings are meticulously crafted to meet international standards, ensuring reliability and longevity. Trusted by clients across various sectors, Elvis Nickel Alloys is your go-to source for premium Monel Forged Fittings in the USA and beyond.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
The Monel forged fittings produced by Elvis Nickel Alloys are primarily made up of nickel (around 63%) and copper (about 28-34%), along with small amounts of iron, manganese, carbon, and silicon. This unique alloy boasts impressive resistance to corrosion, especially in marine and chemical settings. In terms of mechanical properties, these fittings have a tensile strength of roughly 550 MPa, a yield strength of about 240 MPa, and they exhibit good ductility with elongation reaching up to 35%. Monel forged fittings also retain high strength across a broad temperature range, ensuring they perform reliably even in tough conditions.
Contact us to get a quick quote for your requirement.
You’ll find Monel forged fittings from Elvis Nickel Alloys being utilized in a wide array of industries, thanks to their outstanding corrosion resistance and strength. They’re perfect for applications in marine engineering, chemical processing, oil and gas sectors, and power generation. These fittings are often used in piping systems that deal with seawater, acids, alkalis, and other aggressive substances. Their dependability in extreme conditions makes them ideal for heat exchangers, condensers, pumps, and valves. Industries appreciate these forged fittings for their durability, straightforward installation, and minimal maintenance needs, even in challenging service environments.
