Based in Houston, USA, Elvis Nickel Alloys is a reputable Monel Bolt manufacturer and supplier that provides high-end fastening solutions for demanding and corrosive environments. Our Monel bolts, which are made to provide exceptional strength, corrosion resistance, and long-term performance under harsh conditions, come in grades like Monel 400 and Monel K500. These bolts are perfect for the oil and gas, chemical processing, marine, and aerospace industries. Elvis Nickel Alloys makes sure that our Monel bolts satisfy both industry standards and customer-specific requirements by committing to premium materials, accurate engineering, and prompt delivery.
Monel 400 or K500 alloys are used to make Monel bolts. With trace amounts of iron, manganese, and silicon, both have roughly 63% nickel and 28–34% copper. For age-hardening, Monel K500 contains titanium and aluminium. Monel K500 bolts have a high yield strength and superior fatigue resistance, while Monel 400 bolts have a tensile strength of 480–620 MPa. These bolts are extremely resistant to corrosion in seawater, acids, and alkalis and retain their mechanical integrity over a broad temperature range. They are appropriate for high-stress, high-performance applications due to their resilience and durability.
| Specifications | ASTM F 467 ASME SF 467 |
|---|---|
| Standard | IS, ASTM, BS and all International Standards |
| Length | 3 to 200 milimeter |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Screw Type | Monel 400 Threaded Screw, Hex Head Screw, Socket Head Screw, Socket Set Screw, Blind Rivet, Concrete Screw, Shoulder Screw, Anchor Screw, Panel Screw, Machine Screw etc. |
| Bolts Types | Monel 400 Hex Head Bolts, Hex Bolts, Square Bolts, Eye Bolts, T Bolts, U Bolts, Lag Bolts, Counter sunk Bolts etc. |
| Washer Types | Monel 400 Lock Washer, Machine Washers, Star Washers, Sealing Washer, Split Washer etc. |
| Studs Types | Monel 400 Double Ended Studs, Threaded Tod, Tie Bars, Tie Rodsetc. |
| Nut Types | Monel 400 Coupling Nut, Hex Head Nut, Wing Nut, Square Nut, Panel Nut, T Nut, Acorn Nuts, Dome Nut, Eye Nut, Lock Nut etc. |
| Element | Content (%) |
|---|---|
| Nickel, Ni | 63.00 min |
| Silicon, Si | 0.5 max |
| Carbon, C | 0.3 max |
| Sulphur, S | 0.024 |
| Copper, Cu | 28-34 |
| Iron, Fe | 2.5 max |
| Manganese, Mn | 2 max |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength(annealed) | 517-620 MPa | 75-90 ksi |
| Yield strength | 172-345 MPa | 25-50 ksi |
| Modulus of elasticity | 179 GPa | 26000 ksi |
| Poisson’s ratio | 0.32 | 0.32 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Bolts in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel bolts are frequently utilised in settings where durability, strength, and resistance to corrosion are essential. They are utilised in seawater-exposed joints, propeller shafts, and shipbuilding, among other marine applications. Monel bolts are crucial for downhole tools, pumps, valves and other equipment in the oil and gas sector that is subjected to high pressure and sour gas. They are used in reactor vessels, heat exchangers, and corrosive systems in chemical processing facilities. They are essential for structural fasteners that must function in harsh environments in the defence and aerospace industries. Monel bolts are perfect for high-temperature and mission-critical settings because of their dependability and non-magnetic qualities.
