Elvis Nickel Alloys, based in Houston, USA, stands out as a reputable manufacturer and supplier of top-notch Manganese Bronze Sheets and Plates, designed for durability, strength, and resistance to corrosion. With a focus on copper-based alloys, Elvis Nickel Alloys produces precision-engineered manganese bronze products that find their way into marine, automotive, and industrial applications. Renowned for their exceptional mechanical properties and outstanding machinability, these sheets and plates are perfect for components that face heavy loads and harsh environments. Committed to material integrity, high standards, and prompt delivery, Elvis Nickel Alloys is a reliable partner for high-performance bronze alloy solutions.
Manganese Bronze Sheets and Plates mainly consist of Copper (about 55–65%), along with Zinc, Manganese, Aluminum, and trace amounts of Iron. This blend creates a robust, corrosion-resistant alloy with impressive wear resistance. The mechanical properties feature tensile strength typically between 70,000 and 110,000 psi, along with good ductility. The alloy is also highly machinable and can be heat-treated for enhanced strength. Manganese bronze retains its structural integrity under heavy loads, making it ideal for demanding industrial applications. Elvis Nickel Alloys guarantees consistent composition and tight tolerance control for peak performance.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
Manganese Bronze Sheets and Plates are extensively utilized in heavy-duty industrial, marine, and engineering applications that demand strength, wear resistance, and corrosion protection. They are commonly found in ship propellers, pump components, bearings, valve parts, bushings, and structural marine hardware. In the automotive and aerospace industries, these materials are used for gear blanks, hydraulic equipment, and high-load mechanical assemblies. The alloy’s remarkable resistance to seawater and atmospheric corrosion makes it especially valuable in these sectors.
Contact us to get a quick quote for your requirement.
Manganese bronze sheets and plates are widely used in marine and industrial engineering due to their excellent strength, corrosion resistance and durability Typical applications include shipbuilding, where they are used for propeller shafts and fittings, and gears and engine components in the automotive industry will be those encountered in severe environments They are also ideal for machines that heavy duty parts, valves, pumps and marine components. In addition, manganese lead is used for electrical components and structural components requiring high strength and corrosion resistance.
