In Houston, USA, Elvis Nickel Alloys is a top producer and supplier of high-performance Inconel 625 Stud Bolts, providing long-lasting fastening solutions for harsh industrial environments. Even in the harshest conditions, our Inconel 625 stud bolts are designed to provide remarkable strength, resistance to corrosion, and thermal stability. These bolts are perfect for use in refineries, chemical plants, offshore platforms, and aerospace applications because they are made in accordance with ASTM, ASME, and international standards. Elvis Nickel Alloys ensures dependability, accuracy, and long-lasting performance in a variety of international industries by offering custom lengths, threading, and coatings to meet project specifications.
Nickel (≥58%) makes up the majority of Inconel 625 Stud Bolts, with chromium (20–23%), molybdenum (8–10%), and niobium (3.15–4.15%) serving as necessary alloying elements. Excellent resistance to oxidation, pitting, crevice corrosion, and chloride stress corrosion cracking is provided by this special composition. Inconel 625 has remarkable fatigue and creep resistance, as well as a tensile strength of about 827 MPa and a yield strength of about 414 MPa. From cryogenic temperatures to 982°C, these stud bolts operate dependably, preserving structural integrity in demanding environments despite high pressure, stress, and corrosion.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Offshore oil and gas platforms frequently use Inconel 625 Stud Bolts to assemble high-pressure equipment that is subjected to harsh chemicals and seawater. They protect reactors, valves, and flanges that handle corrosive fluids in the petrochemical and chemical industries. They are used in engines and exhaust systems in the aerospace industry where durability and heat resistance are essential. They endure high levels of mechanical and thermal stress in nuclear and power generation facilities. Because they provide dependable fastening where corrosion, heat, and pressure demand maximum reliability, these stud bolts are also crucial in desalination plants and marine engineering applications.
