In Houston, USA, Elvis Nickel Alloys is a reputable manufacturer and supplier of premium Inconel 625 Flanges, offering precisely engineered solutions for the most demanding industrial settings. Our Inconel 625 flanges are renowned for their exceptional strength, resistance to corrosion, and performance under high pressure and high temperature conditions. They are made in accordance with international standards. We provide a large selection of flange types and sizes that are customised to meet the needs of our clients, catering to sectors like power generation, chemical processing, aerospace, and marine. Elvis Nickel Alloys places a high value on quality, dependability, and prompt delivery in order to satisfy the demanding demands of international industries.
Nickel (≥58%) makes up the majority of Inconel 625 Flanges, with notable proportions of chromium (20–23%), molybdenum (8–10%), and niobium (3.15–4.15%). The alloy’s exceptional resistance to oxidation, pitting, crevice corrosion, and chloride stress-corrosion cracking is a result of its composition. With a tensile strength of roughly 827 MPa, these flanges exhibit excellent fatigue and creep resistance over a wide temperature range, ranging from cryogenic to 982°C. Because of their exceptional mechanical strength and stability, Inconel 625 flanges can be used in applications that involve high pressure and harsh chemical exposure.
| Standards | GOST Flange, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092, BS, BS4504, BS 10, EN-1092, DIN, ANSI, ASME, DIN, MSS S44, ISO70051, ANSI/ASME B16.5, ASME/ANSI B16.5/16.36/16.47A/16.47B, B16.47 Series A & B, B16.48, EN |
|---|---|
| Pressure Rating ANSI | Class 1500, Class 150, Class 900, Class 2500, Class 300, Class 600, |
| Pressure Calculation in DIN | 10Bar, 16Bar, 25Bar, 40Bar, 6Bar, / PN16, PN64, PN40, PN25, PN10, PN6 |
| JIS | 16 K, 20 K, 5K, 10 K, 40 K, 63 K, 30 K, |
| UNI | 10Bar 16Bar 6Bar 25Bar 40Bar |
| EN | 6Bar 25Bar 40Bar 10Bar 16Bar |
| Most common Types | Threaded / Screwed / Forged / Plate |
| Production technique | Forged, Heat treated and machined |
| Shapes and Types we produce | Large Male-Female (LMF), Ring Type Joint (RTJ), Flat Face (FF), Small Tongue, Small Male-Female (SMF),Raised Face (RF), Large Tongue & Groove, Groove, Lap-Joint Face (LJF) |
| Test | Direct-reading Spectrograph, Magnetic particle detector, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector |
| Equipment | Pushing Machine, Press machine, Bending machine, Sand-blasting machine, electric bevelling machine etc |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Inconel 625 | 8.4 g/cm3 | 1350 ?C (2460 ?F) | Psi ? 1,35,000 , MPa ? 930 | Psi ? 75,000 , MPa ? 517 | 42.5 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | ? | 5.0 max | 58.0 min | 20.0 ? 23.0 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Flanges in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In chemical processing, Inconel 625 flanges are frequently used to connect pipes and machinery that come into contact with strong acids and solvents. They are used in engine parts, exhaust systems, and high-temperature structural joints in the aerospace sector. Their ability to withstand corrosion makes them perfect for offshore oil rigs and seawater piping in the maritime industry. They are also employed in nuclear power plants, desalination systems, and other applications where the ability to operate at high pressures and temperatures is crucial. Inconel 625 flanges are essential in vital fluid and gas transfer systems because they guarantee long-term dependability and leak-proof connections in harsh environments.
