Based in Houston, USA, Elvis Nickel Alloys is a top producer and supplier of Inconel 617 Tubing, providing premium tubing solutions for industries that operate in harshly corrosive and hot environments. Inconel 617 tubing is well-known for its exceptional strength and resistance to oxidation at elevated temperatures, making it perfect for use in the petrochemical, aerospace, and power generation industries. Our tubes come in a range of sizes, wall thicknesses, and custom specifications and are produced in accordance with strict international standards. Elvis Nickel Alloys offers dependable solutions that are suited to urgent operational requirements with an emphasis on quality, accuracy, and prompt delivery.
Nickel (44.5–60%) makes up the majority of Inconel 617 Tubing, with significant additions of chromium (20–24%), cobalt (10–15%), and molybdenum (8–10%). Excellent resistance to oxidation, carburisation, and high-temperature corrosion is offered by this composition. The tubing maintains its mechanical strength up to 1,093°C (2,000°F) and has a tensile strength of roughly 690–760 MPa. Additionally, under extended heat exposure, it shows good metallurgical stability and creep rupture strength. Inconel 617 tubing is perfect for high-stress, high-temperature applications because it is extremely resilient and keeps its structural integrity in both oxidising and reducing environments.
Specifications ASTM B167, B546 / ASME SB167, SB546,
Dimensions ASTM, ASME and API
Size Range 15″NB – 150″NB
Outer Diameter 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Type Seamless / ERW / Welded / Fabricated / LSAW Pipes
Length Single Random, Double Random & Cut Length
Form Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Hydraulic Tube
Grade 617 UNS (N06617), DIN (2.4663)
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Tubing in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Power generation uses Inconel 617 tubing extensively, especially in high-temperature steam piping, heat recovery systems, and gas turbines. It is used in jet engine parts and exhaust systems in the aerospace sector where resistance to heat and oxidation is essential. It is utilised in reactors, reformers, and furnace tubing that deal with corrosive gases and high operating temperatures in the chemical and petrochemical industries. It is also appropriate for thermal processing equipment, waste incineration systems, and nuclear power plants. When strength, dependability, and corrosion resistance must be maintained in the face of extreme heat, Inconel 617 tubing is the preferred material.
