In Houston, Texas, Elvis Nickel Alloys is a leading producer and supplier of Inconel 601 Wire, a premium grade nickel-chromium alloy wire renowned for its exceptional performance in corrosive and high-temperature conditions. Because of its exceptional resistance to oxidation and scaling at high temperatures, our Inconel 601 wire is intended for use in the chemical, heat treatment, thermal processing, and aerospace industries. Our wire comes in a range of diameters and spool sizes and is manufactured to exacting ASTM, ASME, and international standards. For mission-critical industrial applications worldwide, Elvis Nickel Alloys guarantees accuracy, reliability, and quick delivery.
Nickel (58–63%), chromium (21–25%), and iron (balance) make up the majority of Inconel 601 Wire. Tiny amounts of aluminium (1–1.7%) and carbon (≤0.10%) are added to improve resistance to oxidation and carburisation. It functions well at temperatures up to 1,200°C (2,192°F) and has a tensile strength of roughly 600–700 MPa. Under cyclic heating, the wire shows outstanding metallurgical stability, high mechanical strength, and good creep resistance. Weldable and non-magnetic, Inconel 601 wire maintains its mechanical qualities even after extended exposure to high temperatures.
| Specifications | ASTM B166 ASME SB166, AMS | |
|---|---|---|
| SB 166 UNS N06601 Wires Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Alloy 601 Wires Length | 100 mm TO 6000 mm, customizable | |
| ASTM B166 UNS N06601 Wires Diameter | 10 mm To 100 mm or as per client requirement | |
| 2.4851 Alloy 601 Wires Main Types |
|
|
| Alloy 601 UNS N06601 Wires Density | 8.89 g/cm3 | |
|
580-750 | |
|
as standard | |
|
28-30 | |
| Surface | Polished bright, Smooth | |
| Inconel N06601 Wires Technique | Cold Rolled, hot rolled | |
| Din 2.4851 Wires Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Inconel 601 welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| SB 166 UNS N06601 wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including |
|
|
| Sample | Free sample | |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | N |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 1.00 max | 0.015max | 21.00 – 25.00 | bal | 58.0-63.0 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Wire in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Because of its remarkable resistance to oxidation and spalling, wire is widely used in thermal processing equipment, including furnace elements, radiant tubes, and high-temperature fixtures. It is used in engine parts, exhaust liners, and thermocouple sheathing in the aerospace sector. It is used in the chemical and petrochemical industries for heat exchangers, catalyst support grids, and process heating systems that are subjected to harsh chemicals and high temperatures. It is also appropriate for power generation systems, waste incineration, and nuclear reactors. In the most demanding operating conditions, Inconel 601 wire guarantees long-term performance, durability, and safety.
