High-performance fastening solutions for harsh temperatures and corrosive service environments are provided by Elvis Nickel Alloys, a reputable manufacturer and supplier of Inconel 601 Stud Bolts in Houston, USA. Because of their remarkable resistance to oxidation, carburisation, and high-temperature corrosion, our Inconel 601 stud bolts are designed to satisfy the exacting requirements of the industry. We provide a range of thread sizes, lengths, and finishes to meet the needs of crucial industrial applications, all designed in compliance with ASTM and international standards. Elvis Nickel Alloys provides reliable Inconel 601 fasteners for the aerospace, thermal processing, chemical, and energy industries with a strong emphasis on accuracy, quality, and customer satisfaction.
Nickel (58–63%), chromium (21–25%), and iron (balance) make up Inconel 601 Stud Bolts. Aluminium (1.0–1.7%) is added to improve oxidation resistance. At temperatures as high as 1,200°C (2,192°F), these bolts retain exceptional mechanical stability and offer a tensile strength of approximately 600–750 MPa. Under cyclic heating, they show excellent resistance to spalling and scaling, as well as strong creep resistance and thermal fatigue strength. They are perfect for use in high-stress, high-temperature bolting applications because of their structural integrity and resilience to harsh environments.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Because they offer secure fastening in continuous high-temperature service, Inconel 601 Stud Bolts are frequently used in exhaust systems, industrial ovens, and heat treatment furnaces. They are used in thermal processing equipment, piping systems, and reactors in the chemical and petrochemical industries that are subjected to oxidising agents and acidic environments. They secure parts of engines and exhaust assemblies in the aerospace sector. These bolts are also utilised in nuclear facilities, power plants, and waste incineration systems where oxidation resistance, strength, and durability are essential. In the most severe circumstances, Inconel 601 stud bolts guarantee a long-lasting, leak-proof performance.
