Based in Houston, Texas, Elvis Nickel Alloys is a well-known producer and supplier of Inconel 600 Sheet and Plates. Our speciality is offering high-end nickel-based alloys with remarkable oxidation, corrosion, and heat resistance. Our Inconel 600 products are designed to satisfy the demanding requirements of industrial, thermal, and chemical applications. Elvis Nickel Alloys guarantees dependable, long-lasting, and high-performance solutions thanks to its sophisticated manufacturing procedures and stringent quality control. Serving clients in both domestic and foreign markets, we prioritise accuracy and client satisfaction while providing customised sizes, timely delivery, and affordable prices for all project requirements.
Nickel (minimum 72%) makes up the majority of Inconel 600 Sheets and Plates, with iron (6–10%) and chromium (14–17%) serving as important alloying elements. In a variety of settings, this alloy offers exceptional resistance to corrosion and high temperatures. It has an approximate elongation of 40%, a yield strength of 310 MPa, and a tensile strength of 655 MPa. Inconel 600 provides good weldability and formability while retaining structural integrity under heat stress. It is a dependable option for demanding engineering and industrial settings due to its mechanical strength and resistance to oxidation.
| 600 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 600 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 600 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 600 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 600 Inconel Sheet 3.0–10.0 mm |
| 600 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 600 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 600 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 600 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 600 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 600 Inconel Strips EN 10088 SA -240-600 Strips |
| Finish of Inconel 600 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 600 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Sheets and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Industries needing high-temperature strength and corrosion resistance frequently use Inconel 600 Sheets and Plates. Heat exchangers, furnace parts, chemical processing machinery, nuclear reactor parts, and aerospace parts are a few examples of applications. It is perfect for offshore and marine applications due to its resistance to corrosion cracking caused by chloride-ion stress. Additionally, Inconel 600 excels in caustic settings like food processing and the production of alkaline chemicals. Because of its adaptability and resilience to high temperatures and corrosive environments, it is a material of choice for engineers and fabricators working in the petrochemical, energy, and high-temperature processing sectors.
