Elvis Nickel Alloys is a well-known manufacturer and supplier of Incoloy Pipe in Houston, USA, supplying seamless and welded pipes of different varieties for high-temperature and corrosive applications. Our Incoloy pipes come in grades like 800, 800HT, and 825 that are capable of resisting oxidation, carburization, and acid attack. Perfect for petrochemical, marine, aerospace, and nuclear power industries, our pipes are manufactured to international quality, size, and performance standards. Supported by cutting-edge manufacturing and inspection techniques, Elvis Nickel Alloys provides Incoloy pipes that provide long-term reliability and integrity even in the most extreme conditions.
Incoloy Pipe is fabricated from nickel-iron-chromium alloy compositions supplemented with molybdenum, titanium, and copper. The alloy combines high mechanical strength (tensile strength to 750 MPa), high yield strength, and stress rupture resistance at high temperatures. It resists acid, seawater, and oxidizing agent corrosion. Incoloy pipe further exhibits high thermal stability, good weldability, and superior mechanical performance under pressure and cyclic loading. These features render it appropriate for long-term use in hostile chemical and elevated heat conditions.
Specifications : ASTM B423, B705, B704 / ASME SB423, SB705, SB704
Standard : ASTM, ASME and API
Size : 15″NB – 150″NB
Outer Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Length : Single Random, Double Random & Cut Length
Schedule : SCH 10, SCH20, SCH30, SCH50, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / ERW / Welded / EFW / Fabricated / CDW
| Grade | C | Al | Ti | S | Cu | Fe | Ni |
| Incoloy Pipe | 0.05 max | 0.2 max | 0.6 – 1.2 | 0.03 max | 1.5 – 3.0 | 22.0 min | 38.0 – 46.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Pipe | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Pipes in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy Pipe finds applications in numerous high-stress and corrosive situations. Some typical applications include chemical plant process piping, nuclear reactors, refineries, and power generation plants. It is also employed for the movement of hot, corrosive liquids in marine and offshore systems. Incoloy pipes are perfectly suited for sulfuric acid plants, seawater cooling systems, exhaust ducts, and industrial furnaces. Their thermal expansion resistance and scaling resistance make them perfectly well-placed to be used in flue gas systems and waste heat recovery equipment. Incoloy‘s longevity, strength, and corrosion resistance ensure that it is a first choice for mission-critical flow systems in extremely aggressive environments.
