Premium-grade Incoloy Flanges are available to customers all over Dubai, United Arab Emirates, from Elvis Nickel Alloys, a respectable manufacturer and international supplier with its headquarters located in Houston, USA. These flanges are well-known for being strong and resistant to corrosion, high pressure, and heat, making them perfect for demanding industrial applications. Elvis produces flanges that satisfy international standards such as ASTM B564, and they are available in a variety of grades, including Incoloy 800, 800H, 800HT, and 825. These flanges, which are extensively utilised in the petrochemical, power generation, and offshore sectors in the United Arab Emirates, are made to withstand corrosion and leaks in harsh chemical and marine environments.
Depending on the grade, Molybdenum, Copper, Titanium, and Aluminium are added to the nickel (30–46%), chromium (19–23%), and iron (balance) that make up Elvis Nickel Alloys’ Incoloy Flanges. These alloys exhibit exceptional resistance to corrosive environments, carburisation, and high-temperature oxidation. The typical tensile, yield, and elongation strengths of incoloy flanges are 500–700 MPa, 200–450 MPa, and 45%, respectively. They are ideal for use in heat exchangers, pressure vessels, and piping systems in the chemical and energy industries due to their mechanical stability at high temperatures.
Specifications : ASTM B 564 / ASME SB 564
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Standards : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges etc.
Size : 1/2″ to 36″
Pressure Rating : Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
| C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti | |
| Incoloy | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy Flanges | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Flanges in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Chemical plants, oil refineries, power plants, nuclear reactors, and marine environments all make extensive use of Incoloy Flanges from Elvis Nickel Alloys. They are perfect for process piping, heat exchangers, and offshore oil and gas platforms because of their exceptional resistance to corrosion, particularly against acids like sulphuric, nitric, and phosphoric acid. While Incoloy 800 series flanges are ideal for high-temperature structural applications, Incoloy 825 flanges are especially useful in acid-handling systems. These flanges, which come in weld neck, blind, slip-on, and socket weld varieties, guarantee safe, high-integrity connections in demanding industrial processes.
