Based in Houston, USA, Elvis Nickel Alloys is a well-known manufacturer and supplier of premium-grade Incoloy 825 Sheets and Plates that caters to important industrial sectors in Dubai, United Arab Emirates. These nickel-iron-chromium alloy plates, which are manufactured in accordance with ASTM B424 and ASME standards, offer exceptional resistance to acid attack, particularly in environments that contain phosphoric and sulphuric acids. Because of their exceptional mechanical stability and resistance to corrosion, Incoloy 825 sheets and plates are frequently utilised in petrochemical, offshore, and pollution control systems. Elvis Nickel Alloys provides customised thicknesses and sizes with an emphasis on dependability, quality, and longevity under harsh service circumstances.
Nickel (~38–46%), Chromium (~19.5–23.5%), Iron (balance), Molybdenum (~2.5–3.5%), Copper (~1.5–3%), and Titanium (~0.6–1.2%) make up Incoloy 825 Sheets and Plates from Elvis Nickel Alloys. Excellent resistance to stress corrosion, pitting, cracking, and reducing and oxidising acids is provided by this composition. Tensile strength of 585 MPa, yield strength of 240 MPa, and elongation of about 30% are typical mechanical characteristics. These plates are perfect for high-stress and chemically aggressive environments because they retain their mechanical stability and resistance to corrosion at temperatures as high as 540°C.
Specifications : ASTM B409 / ASME SB409, AMS 5877
Dimensions : ASTM, ASME, and API
Incoloy Sheet : thickness range from .008″ to .0125″
Incoloy Plate : thickness ranges from .0125″ to 5.00″
Size : 15NB to 150NB In
Tempers : Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Sheets Plates | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Sheets and Plates | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Sheets and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Sheets and Plates from Elvis Nickel Alloys are widely used in oil and gas exploration, acid production, chemical processing, marine outfall systems and nuclear waste reprocessing in Dubai and throughout the United Arab Emirates. They are ideal for use in heat exchangers, piping systems, and acid storage tanks due to their exceptional resistance to phosphoric, nitric, sulphuric, and hydrochloric acids. These plates are also utilised in pickling processes, seawater handling systems, and pollution control equipment, where exceptional corrosion resistance and high strength are crucial. In demanding industrial settings, Incoloy 825 provides durable performance.
