At Elvis Nickel Alloys, based in Texas, USA, we specialize in delivering high-quality Incoloy 825 Coils, renowned for their exceptional resistance to corrosion and oxidation. Our Incoloy 825 Coils are meticulously engineered to withstand harsh environments, making them ideal for a range of industrial applications. As a leading manufacturer and supplier, we pride ourselves on providing products that meet rigorous industry standards, ensuring durability and reliability for our clients’ critical projects.
Specifications : ASTM B424 / ASME SB424
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled (HR), Cold rolled coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Coils, Shim Coils, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 32,000 , MPa – 220 | Psi – 80,000 , MPa -550 | 30 % |
The Incoloy 825 Coils from Elvis Nickel Alloys are crafted from a nickel-iron-chromium base alloy, enriched with notable amounts of molybdenum, copper, and titanium. These added elements significantly boost corrosion resistance in both acidic and oxidizing environments. The coils showcase impressive mechanical properties, featuring a tensile strength of around 85 ksi, yield strength of 40 ksi, and an elongation of 30%. Their robustness and thermal stability make them perfect for high-temperature applications, and they maintain their strength across a wide range of pressures, making them an excellent choice for challenging industrial settings.
Elvis Nickel Alloys’ Incoloy 825 Coils find extensive use in sectors like chemical processing, marine engineering, pollution control, and oil and gas refining. Their outstanding resistance to corrosion and oxidation in both reducing and oxidizing conditions makes them ideal for heat exchangers, evaporators, tanks, and piping systems. Moreover, their ability to handle acids such as sulfuric and phosphoric makes them suitable for acid production facilities. The coils’ dependability under high stress and temperature conditions also makes them a favored option in nuclear and power generation plants.
