Varun Sheets and Plates stands out as a top-notch manufacturer and supplier of Incoloy 800, 800H, and 800HT Sheets and Plates, proudly based in Dubai, UAE. We specialize in high-temperature and corrosion-resistant alloys, catering to essential industries like petrochemical, power generation, heat treatment, and refinery operations. Our Incoloy 800 series sheets and plates are crafted with precision and rigorous quality control, guaranteeing exceptional strength, dimensional stability, and long-lasting performance even in the toughest thermal and chemical conditions. With reliable logistics throughout the Middle East, Varun is committed to delivering tailored solutions that meet complex industrial needs.
Incoloy 800, 800H, and 800HT are nickel-iron-chromium alloys designed for outstanding high-temperature strength and remarkable resistance to oxidation, carburization, and sulfidation. The 800H and 800HT grades come with higher carbon content and controlled grain size, enhancing their stress rupture and creep resistance. These sheets and plates boast tensile strength between 500 to 600 MPa and maintain excellent metallurgical stability, even when exposed to prolonged heat.
Specifications : ASTM B409 / ASME SB409, AMS 5877
Dimensions : ASTM, ASME, and API
Incoloy Sheet : thickness range from .008″ to .0125″
Incoloy Plate : thickness ranges from .0125″ to 5.00″
Size : 15NB to 150NB In
Tempers : Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Sheets Plates | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Sheets and Plates | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Sheets and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Our Incoloy 800/800H/800HT Sheets and Plates are extensively utilized in high-temperature settings such as heat exchangers, furnaces, hydrocarbon cracking units, superheater tubing, and chemical process vessels. Their exceptional resistance to high-temperature corrosion and ability to retain strength under mechanical stress make them perfect for structural and pressure applications. Available in a range of sizes, thicknesses, and finishes, Varun’s Incoloy sheets and plates are engineered to meet international standards, ensuring reliable performance in the most demanding operational environments.
