Elvis Nickel Alloys, a leading manufacturer and supplier based in Texas, USA, specializes in providing high-quality Incoloy 800, 800H, and 800HT coils. Known for their exceptional resistance to high temperatures and corrosion, these coils are widely used in industries such as petrochemical, power generation, and chemical processing. At Elvis Nickel Alloys, we are committed to delivering reliable and durable solutions that meet the specific needs of our global clientele, ensuring the highest standards of quality and performance.
| Standard | ASTM B409 / ASME SB409 |
|---|---|
| Thickness | 0.2mm – 5.0mm |
| Width | 3.2mm – 1500mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Test Certificate | Yes |
| Coils Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Form | Coil / Strip |
| Make | Jindal, Bahru, Posco Korea, Posco Thainox, Columbus, Acerinox, Aperam, Tisco, Nisshin, Nippon And Many More Mills. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Alloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Alloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Alloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Incoloy 800/800H/800HT Coils mainly consist of nickel (30–35%), chromium (19–23%), and iron, with minor additions of aluminum and titanium to boost stability. These alloys showcase excellent mechanical strength and high resistance to stress rupture and creep at elevated temperatures. The Incoloy 800H and 800HT variants offer enhanced performance thanks to their higher carbon content and meticulous control of grain size. These coils maintain remarkable metallurgical stability and oxidation resistance during prolonged thermal exposure, making them perfect for high-temperature industrial applications.
Incoloy 800/800H/800HT Coils find extensive use in sectors like petrochemical processing, power generation, nuclear energy, and chemical manufacturing. They are utilized in applications such as heat exchangers, superheaters, furnace components, and reheater tubing, where resistance to oxidation and carburization is crucial. Their excellent thermal stability and long-lasting performance make them ideal for environments with extreme temperatures and corrosive substances. The durability and low maintenance needs of these coils enhance operational efficiency and reliability in critical industrial systems.
