Elvis Nickel Alloys, based in Houston, USA, is a reliable manufacturer and supplier of Haynes 25 / L605 Bars, celebrated for their exceptional strength, resistance to oxidation, and performance at high temperatures. Crafted from a cobalt-nickel-chromium-tungsten alloy, these bars are engineered to thrive in harsh environments with high heat and corrosive conditions. Elvis Nickel Alloys adheres to strict standards like ASTM F90 and AMS 5759, guaranteeing top-notch mechanical integrity and surface quality. These bars find their place in aerospace, gas turbines, medical devices, and industrial furnace applications, where durability and metallurgical stability are essential for optimal performance.
Haynes 25 / L605 Bars are primarily made up of Cobalt (~51%), Chromium (~20%), Nickel (~10%), and Tungsten (~15%), along with trace elements that boost performance. This alloy is known for its remarkable high-temperature strength, oxidation resistance up to 1093°C (2000°F), and solid resistance to sulfidation and wear. With typical tensile strength surpassing 130,000 psi, it also boasts excellent creep and fatigue resistance. The bars are easy to fabricate and weld. Elvis Nickel Alloys maintains rigorous quality control, precise dimensional tolerances, and certified mechanical properties, making Haynes 25 bars perfect for extreme service conditions in aerospace and industrial settings.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Haynes 25 / L605 Bars are widely utilized in scenarios that require high strength, oxidation resistance, and thermal stability at elevated temperatures. In the aerospace sector, they are essential for turbine engine components like combustion chambers, afterburners, and exhaust systems. Gas turbine manufacturers rely on them for blades, seals, and liners. In the medical field, Haynes 25 is prized for its biocompatibility in surgical tools and implantable devices. Additionally, it finds applications in industrial furnaces, nuclear reactors, and petrochemical processing, where its durability and performance are crucial.
