Elvis Nickel Alloys, a leading manufacturer and supplier located in Houston, USA, specializes in high-quality Hastelloy N Wire, designed for tough applications in nuclear, chemical, and high-temperature settings. Also referred to as UNS N10003, Hastelloy N is a nickel-molybdenum alloy crafted specifically for molten salt reactors (MSRs) and boasts remarkable resistance to fluoride salts, extreme temperatures, and corrosion. The wire comes in various diameters and spool formats, adhering to standards like ASTM B622 and ASME SB622. Hastelloy N Wire is extensively utilized in nuclear energy systems, aerospace, chemical processing, and heat transfer equipment.
Hastelloy N Wire mainly consists of nickel (around 71%), with 16–18% molybdenum, 5–7% iron, 4–6% chromium, and trace amounts of elements like silicon, cobalt, and manganese. This alloy is engineered for outstanding performance in fluoride salt environments and maintains its strength even at high temperatures. It typically shows a tensile strength of about 690 MPa, a yield strength of around 280 MPa, and an elongation of at least 40%. Hastelloy N Wire keeps its mechanical integrity over long service periods, even in high-radiation or thermal cycling conditions, making it perfect for advanced nuclear reactor designs.
| Standards : | ASTM B573, ASME SB573 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | Si | Cu | Ni | Cr | Mo | W | Fe |
| Hastelloy N | 0.06 max | 0.8 max | 1.00 max | ≤ 0.35 | 71 Balance | 6.0 – 8.0 | 15.0 – 18.0 | ≤ 0.50 | ≤ 5 |
| Tensile Strength | Modulus of elasticity (@14°C) | Elongation |
| Psi – 800 , MPa –116000 | Psi – 219 , Ksi – 31800 | 39.3 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy N Wire in Texas, UAE, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the UAE, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy N wire is mainly used in high temperature and corrosive environments, especially in medical, aerospace, power generation applications etc. Exceptional resistance to high temperature oxidation, carburization and sulfidation makes it ideal for use in applications such as furnace components, high temperature heat exchangers , chemical process reactors They are also used in the manufacture of equipment for nuclear reactors, as well as for use in the aerospace industry for materials in extreme temperatures and corrosive gases.
