Elvis Nickel Alloys provides high–quality Hastelloy C22 Forged Fittings from Houston, USA. These fittings are exclusively made for application in aggressive chemical process systems, where high mechanical strength and resistance to corrosion are needed. Hastelloy C22 Forged Fittings are best suited for high pressure conditions, with superior performance against crevice corrosion, pitting, and stress corrosion cracking. Coming in numerous shapes and configurations, our forged fittings find extensive application in leak-free joint requirements in systems under severe chemical and thermal stress.
| Standard | ASTM B564 / ASME SB564 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Hastelloy C22 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Balance | 0.010 max | 12.5 – 14.5 | 0.50 max | 0.08 max | 2 – 6 | 0.02 max | 0.02 max | 2.5 max | 20 – 22.5 | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | Psi – 1,00,000 , MPa – 690 | 45 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Forged Fittings in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy C22 Forged Fittings find extensive use in piping systems of chemical processing, petrochemicals, pollution control, and marine environments. The fittings provide leak-tight connections in high-pressure systems carrying aggressive fluids like sulfuric acid, hydrochloric acid, and nitric acid. Uses of the fittings include desalination plants, power generation systems, reactors, and scrubbers. Their resistance to reducing and oxidizing conditions renders them ideal for multipurpose systems subject to changing chemical environments. For pharmaceutical manufacturing and wastewater treatment, these fittings assist with system reliability, safety, and performance in aggressive corrosive service.
