Elvis Nickel Alloys is a premier supplier and manufacturer of Duplex Steel S32205 Wire, providing high-quality wire solutions from our Houston, USA facility. Recognized for their high strength and corrosion resistance, our Duplex S32205 wire is produced in numerous forms including coils, spools, and straight lengths, customized to fulfill various industrial needs. We make sure to maintain precision and consistency in each batch with the help of advanced drawing and annealing processes. Extensively employed in chemical, marine, and structural industries, our Duplex Steel Wire is distinguishable for weldability, versatility, and long-term stability even under hostile and high-stress conditions.
Our Duplex Steel S32205 Wire contains around 22% chromium, 5–6% nickel, 3% molybdenum, and nitrogen. The alloy composition increases corrosion resistance and mechanical strength. It has tensile strength of approximately 620 MPa, yield strength of more than 450 MPa, and satisfactory elongation, facilitating ductility and formability. Its duplex microstructure provides excellent workability and corrosion resistance under stress. Duplex wire can tolerate high thermal and mechanical stress and withstands it, which is ideal for weaving, welding, and other fabrication processes that require high performance and reliability for a long time.
| Duplex Wire Standard | ASTM A276, A479 / ASME SA276, SA479 AMS 5514 |
|---|---|
| Duplex Steel / Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Duplex Wire Length | Cut Lengths: 0.125″ to 72″ No Limit on Spooled Lengths |
| Duplex Wire Diameter | 0.0004″ to 0.040″ 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
|
580-750 |
|
as standard |
|
28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| S31803 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 21.0 – 23.0 | 4.5- 6.5 | 2.5 – 3.5 | 0.08 – 0.20 |
| S32205 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 22.0 – 23.0 | 4.5- 6.5 | 3.0 – 3.5 | 0.14 – 0.20 |
| Tensile Strength | 650 -850MPa |
| Elongation (Min) | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel S32205 Wire in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel S32205 Wire finds application in many industries such as oil and gas, chemical processing, marine, and architectural. It is suitable for safety wire, welding electrodes, filtration mesh, spring production, and reinforcement in aggressive conditions. It prevents salt-induced corrosion and stress cracking in marine and coastal structures. In the pulp & paper and desalination industries, it provides longevity in acidic or salty conditions. The wire also finds application in heat exchangers and industrial screens. With its outstanding strength and corrosion resistance, Duplex wire delivers reliable performance in demanding applications where accuracy and longevity are essential.
