At Elvis Nickel Alloys, we pride ourselves on being a leading manufacturer and distributor of high-quality Duplex Steel 2205 tubing in Texas, USA. Our Duplex Steel 2205 tubing is renowned for its superior strength, excellent corrosion resistance, and durability, making it a top choice for challenging environments such as oil and gas, marine, and chemical processing industries. We are committed to delivering exceptional products that meet rigorous industry standards, ensuring reliability and performance. Trust Elvis Nickel Alloys for all your Duplex Steel 2205 needs, and experience unmatched quality and service.
|
Standard |
: |
ASTM A789 /ASME SA 789 |
|
Type |
: |
Seamless Tubes |
|
Grade |
: |
UNS S31803 & UNS S32205 |
|
Size |
: |
1/2″NB TO 12 “NB IN |
|
Thickness |
: |
0.5-45mm |
|
Outer Diameter |
: |
6.0-630mm |
|
Dimensions |
: |
OD(6.0-630)*WT(0.5-45)mm |
|
Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80 |
|
Length |
: |
Single Random, Double Random & Cut Length |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
2205 |
Min Max |
– 0.030 |
– 2.00 |
– 1.00 |
– 0.030 |
– 0.020 |
21.0 23.0 |
2.5 3.5 |
4.5 6.5 |
0.08 0.20 |
| Mechanical properties | Tensile,min,ksi[MPa] | Yield,min,ksi[MPa] | Elongation,%(min) | Hardness,HB(max) |
| 2205 | 95 [655] | 65 [450] | 25 | 290 |
Duplex Steel 2205 Tubing is composed of approximately 22% chromium, 5-6% nickel, 3% molybdenum, and nitrogen, which gives it remarkable corrosion resistance, especially in chloride environments. It boasts nearly double the yield strength of standard austenitic stainless steel, with a tensile strength of around 620 MPa, yield strength of about 450 MPa, and an elongation of 25%. The balanced duplex microstructure provides high fatigue strength, excellent resistance to pitting and crevice corrosion, and enhanced resistance to stress corrosion cracking, making Duplex 2205 tubing perfect for demanding applications.
Contact us to get a quick quote for your requirement.
This tubing is widely used in sectors like oil and gas, chemical processing, marine engineering, desalination, and pulp and paper. It’s particularly suited for applications that require high strength and outstanding corrosion resistance, such as heat exchangers, pressure vessels, structural supports, and piping systems exposed to seawater and chloride-rich environments. Its impressive mechanical properties and resistance to harsh media also make it a great choice for architectural structures, bridges, and other load-bearing components where durability and a long service life are crucial.
