At Elvis Nickel Alloys, we proudly offer premium Duplex Steel 2205 sheets and plates, renowned for their exceptional strength, corrosion resistance, and durability. As a leading manufacturer and distributor based in Texas, USA, we ensure that our products meet the highest standards of quality and performance. Our Duplex Steel 2205 solutions are perfect for a wide range of industrial applications, delivering superior reliability and longevity. With a commitment to excellence and customer satisfaction, Elvis Nickel Alloys stands out as the trusted choice for high-grade materials in the region. Explore our range to find the ideal solution for your needs.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| 2205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
Our Duplex Steel 2205 Sheets and Plates are crafted from a blend of approximately 22% chromium, 5-6% nickel, 3% molybdenum, along with trace amounts of nitrogen, manganese, and iron. These products boast impressive mechanical properties, featuring a high yield strength of around 450 MPa, tensile strength close to 620 MPa, and good elongation. The alloy is known for its exceptional fatigue strength, hardness, and resistance to stress corrosion cracking, making it ideal for demanding applications in harsh environments where superior strength and corrosion resistance are essential.
Contact us to get a quick quote for your requirement.
Our Duplex Steel 2205 Sheets and Plates are crafted from a blend of approximately 22% chromium, 5-6% nickel, 3% molybdenum, along with trace amounts of nitrogen, manganese, and iron. These products boast impressive mechanical properties, featuring a high yield strength of around 450 MPa, tensile strength close to 620 MPa, and good elongation. The alloy is known for its exceptional fatigue strength, hardness, and resistance to stress corrosion cracking, making it ideal for demanding applications in harsh environments where superior strength and corrosion resistance are essential. Duplex Steel 2205 sheets and plates are widely used in industries requiring high strength and corrosion resistance. Common applications include chemical processing, oil and gas, marine environments, and pulp and paper production. They are ideal for pressure vessels, storage tanks, heat exchangers, and structural components exposed to harsh conditions. Their durability and resistance to chloride stress corrosion make them suitable for applications where high performance and longevity are critical.
