Home > Duplex Steel > Duplex Ball Valve
One of the top producers and suppliers of duplex ball valves in Texas, USA, is Elvis Nickel Alloys. Our valves are perfect for demanding industrial applications because of their remarkable strength, resilience to corrosion, and durability. They work well in power plants, chemical plants and offshore oil and gas facilities because they are built to be dependable in high-pressure settings. Each valve is put through a rigorous testing process to meet industry standards and ensures superior performance, longevity, and suitability for demanding operating conditions. This is done with a commitment to quality.
Duplex ball valves provide high strength and durability with high corrosion resistance particularly in hostile environments. They have high resistance to erosion and stress corrosion cracking and are well suited for use in high-temperature and high-pressure applications. The valves give reliable leak-free performance and retain performance under extreme conditions. Their high strength and good mechanical properties allow them to find application in chemical processing, marine, oil and gas and power generation sectors, which provide long-term reliability and efficiency.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | UTS (MPa) | % Elongation | Hardness(BHN) | YS (MPa) |
| 31803 | 620 min. | 25 min. | 293 max. | 450 min. |
| 2205 | 655 min. | 25 min. | 293 max. | 450 min. |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Ball Valve in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex ball valves find extensive use in industries where corrosion resistance and high strength are needed. They are best suited for use in the chemical industry, marine conditions and oil and gas production, where performance under stressful conditions and resistance to corrosion are essential. These are utilized in power plants and high-pressure systems, where they manage to manage aggressive chemicals and extreme temperatures Their durability guarantees faultless operation, leak proof for demanding applications and hostile environments Suitable.
