Home > Copper Nickel > Copper Nickel 90/10 Forged Fittings
Elvis Nickel Alloys, a trusted manufacturer and supplier located in Houston, USA, specializes in high-quality Copper Nickel 90/10 Forged Fittings designed for durability and resistance to corrosion in tough marine and industrial settings. Crafted from UNS C70600, these fittings are made up of 90% copper and 10% nickel, with small amounts of iron and manganese added to boost strength and enhance resistance to seawater corrosion. They come in various forms, including socket welds, threaded elbows, tees, couplings, and unions, and comply with international standards like ASTM B122/B467 and ASME B16.11, ensuring top-notch performance in high-pressure situations.
Copper Nickel 90/10 Forged Fittings are made up of about 90% copper and 10% nickel, along with trace elements of iron (~1.5%) and manganese (~1%) to improve corrosion resistance and mechanical properties. These fittings boast a tensile strength ranging from 275 to 350 MPa, a yield strength of around 105 MPa, and impressive elongation (≥30%). They maintain their structural integrity even at high temperatures, are non-magnetic, and resist biofouling, pitting, and erosion in seawater. The forging process guarantees a dense, defect-free metal with exceptional mechanical strength, making them perfect for high-pressure and corrosive environments.
Cupro Nickel Forged Fittings Specification : ASTM B467 / ASME SB467
Dimension Standard : ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cupro Nickel 90/10 | 88.6 | 1.0 max | 0.05 max | 9 – 11 max | 1.8 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Forged Fittings in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper nickel 90/10 forged fittings are widely used in the marine and industrial industries due to their high resistance to marine corrosion. It is commonly used in shipbuilding for marine piping systems, condensers, heat exchangers and pipelines. In addition, these materials are used in offshore oil and gas plants, desalination plants and power plants. Its resistance to high temperatures and pressures makes it particularly suitable for use in the chemical industry, fire suppression, and other areas where durability and corrosion resistance are required.
