Based in Houston, Texas, George Metals is a top producer and supplier of high-grade copper nickel 70/30 pipes for use in offshore, industrial, and marine settings. High-grade 70/30 copper-nickel alloy, which is used in the engineering of our pipes, provides exceptional strength and corrosion resistance, particularly in harsh brine and seawater environments. These pipes, which are made to international standards, guarantee outstanding weldability, long-term durability, and dependability in high-pressure and high-temperature environments. George Metals is dedicated to providing precisely engineered Copper Nickel 70/30 Pipes that satisfy the requirements of vital systems in the chemical processing, power generation, desalination, and shipbuilding sectors.
About 70% copper and 30% nickel make up copper nickel 70/30 pipes, with trace amounts of iron and manganese added to increase strength and resistance to corrosion. This alloy guarantees flexibility and durability with its high tensile strength, which normally ranges between 350 and 550 MPa, and excellent elongation values up to 30%. In high-velocity seawater, the 70/30 composition offers exceptional resistance to pitting, stress corrosion cracking, and erosion. It is perfect for use in heat exchangers, condensers, and other pressure-based fluid handling systems because of its exceptional thermal conductivity and stability at high temperatures.
| ASTM Specification | ASTM B466/ ASME SB466, ASTM B467/ ASME SB467, ASTM B608 |
|---|---|
| Standard | GB, DTD, ASME, AISI, ASTM, TOCT, JIS, NF, SAE, DIN, AMS, DS, EN |
| Size of Seamless Pipe | Wall thickness.: 0.05- 20 milimeter, 4 – 219 milimeter |
| Size of Welded Pipe | 5.0 to 1219.02 milimeter |
| size of EFW Pipe | 5.0 to 1219.02 milimeter |
| Seamless Tube Size | 3.35 milimeter To 101.6 milimeter OD |
| Welded Tube Size | 6.35 milimeter To 152 milimeter OD |
| Bwg & Swg | 18 Swg., 14 20 Swg., Swg. Swg., 12 16 Swg., 10 Swg. |
| Tubing wall thickness | 0.020″ –0.220″, (custom wall thicknesses available) |
| Pipe Schedule | SCH20, XS, STD, XXS, SCH60, SCH140, SCH80, SCH80, SCH5, SCH40S, SCH40, SCH120, SCH10S, SCH10, SCH30, SCH160 |
| Length | Standard & Cut length , Single Random, Double Random Pipe |
| Finish | AP (Annealed & Pickled), BA (Bright & Annealed), NO.1, 2B, Polished, MF, HL, NO.4, Mirror finish, BA, 8K etc |
| End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Form | Hydraulic, Rectangular, Coiled, Square, Hollow, Round, Straight Pipes/tubes, “U” Shape, Pan Cake Coils, Boiler, LSAWetc. |
| Application | Dairy Pipe, Oil Pipe/tube, Gas Pipe/tube, Fluid Pipe/tube, Boiler Tube, Heat exchanger Tube |
| Type | Seamless /ERW/ EFW / Welded / Fabricated /CDW /DOM/CEW Copper Nickel 70/30 Pipe |
| Cu | Pb | Mn | Fe | Zn | Ni | |
|---|---|---|---|---|---|---|
| MIN | 65.000 | – | – | 0.400 | – | 29.000 |
| MAX | 70.000 | 0.500 | 1.000 | 1.000 | 1.000 | 33.000 |
| Yield Strength 0.2% Proof (MPa) |
Yield Strength 0.2% Proof (MPa) |
Tensile strength (MPa) |
Elongation (% in 50mm) |
Hardness (HRB) |
|---|---|---|---|---|
| MIN | 88 | 372 | 45.00 | |
| MAX | 483 | 517 | 51 |
| Density | kg/dm³ | 8.95 |
|---|---|---|
| Melting Range | °C | 1170-1240 |
| Specific Heat | J/kg °K | 377 |
| Thermal Conductivity | W/m°K | 29 |
| Coeff. of Linear Expansion 10-300°C” | 10-6/°K | 16 |
| Electrical Resistivity | microhm. cm | 34 |
| Modulus of Elasticity | GPa | 152 |
| Modulus of Rigidity | GPa | 56 |
At Elvis Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 70/30 Pipes in Texas, USA, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the USA, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In industries where exposure to seawater and harsh conditions is frequent, copper nickel 70/30 pipes are widely used. They are essential for firewater, ballast, bilge systems, and seawater cooling in the maritime and shipbuilding industries. These pipes are essential for high-pressure fluid transfer in corrosive environments on offshore oil and gas platforms. They are also used in chemical processing systems, desalination plants, and power generation facilities where corrosion prevention, heat resistance, and durability are crucial. In order to ensure long-lasting performance and structural integrity in the most demanding operating environments, George Metals provides Copper Nickel 70/30 Pipes.
