Elvis Nickel Alloys stands out as a top-notch manufacturer and supplier based in Houston, USA, specializing in high-quality AWS Class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod. With a keen emphasis on precision, durability, and reliability, this company meets the rigorous demands of various industries, including petrochemical, power generation, marine, and aerospace. Elvis Nickel Alloys is dedicated to delivering welding consumables that not only meet international standards but also excel in critical applications. Their AWS Class ERNiCrMo-10 filler wires and rods are highly regarded for their outstanding corrosion resistance and mechanical integrity, even in the toughest service conditions.
The AWS Class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod is primarily composed of nickel, chromium, molybdenum, and iron, along with trace amounts of copper and other alloying elements. This specific blend guarantees exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, especially in harsh chemical and marine environments. The material boasts high tensile strength, good ductility, and toughness, ensuring stability even at elevated temperatures. Its mechanical properties facilitate smooth weldability, resulting in clean, high-quality weld beads with minimal spatter and robust metallurgical bonds.
| Classification | AWS A5.14, ERNiCrMo-10 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-10 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Co | Cr | Mo | V | W | Other |
| 0.015 | 0.50 | 2.0-6.0 | 0.02 | 0.010 | 0.08 | 0.50 | Rem | 2.5 | 20.0-22.5 | 12.5-14.5 | 0.35 | 2.5-3.5 | 0.5 |
| Tensile (psi) | 100,000 |
|---|---|
| Mpa | 690 |
| Elongation (%) | 30 |
Widely utilized in the chemical processing, offshore, and marine sectors, the AWS Class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod is perfect for fabricating and repairing components like heat exchangers, pressure vessels, and piping systems. Its remarkable corrosion resistance makes it an excellent choice for applications exposed to seawater, acids, and chlorides. Additionally, this filler material is adept at welding dissimilar metals and overlaying surfaces that need enhanced corrosion protection. It performs reliably in both manual and automated welding processes, ensuring strong, durable joints in critical structures and equipment.
Contact us to get a quick quote for your requirement.
AWS class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod is widely used in applications requiring high corrosion resistance and high thermal properties. Ideal for welding nickel-chromium and molybdenum alloys including those found in chemical, petrochemical and marine environments. It is also used to combine different types of metals, including stainless steels and high-strength alloys. The high resistance to oxidation and erosion makes it suitable for critical applications in aerospace and power generation, as well as the repair and maintenance of high-performance products.
