Elvis Nickel Alloys Manufacturer and Supplier in Texas, USA, proudly offers AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod, designed for high-performance welding applications. Renowned for its exceptional corrosion resistance and durability, this filler material is ideal for welding nickel-chromium alloys and stainless steels. It provides superior weldability, excellent mechanical properties, and outstanding resistance to oxidation, making it a trusted choice for demanding industrial environments and critical applications.
Elvis Nickel Alloys, located in Houston, USA, is a reliable manufacturer and supplier of AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod. With a strong commitment to quality and precision, the company offers high-performance nickel alloy filler materials that meet global standards. Our ERNiCr-3 filler wire and rod are designed for exceptional weldability, corrosion resistance, and mechanical strength, catering to the needs of critical industries. We proudly serve sectors such as aerospace, chemical processing, marine, and power generation, ensuring timely delivery, competitive pricing, and outstanding customer support throughout the USA and beyond.
| Classification | AWS A5.14, ERNiCr-3 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCr-3 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Ti | Cr | Tb+Ta | Other |
| 0.10 | 2.5-3.5 | 3.0 | 0.03 | 0.015 | 0.50 | 0.50 | 67.0 min | 0.75 | 18.0-22.0 | 2.0-3.0 | 0.50 |
| Tensile Strength | 85,500 psi |
|---|---|
| Yield Strength | 52,500 psi |
| Elongation | 38% |
The AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod primarily consist of nickel (approximately 67%), chromium (20-23%), and iron (up to 3%), along with trace amounts of manganese, copper, silicon, and carbon. This alloy boasts a tensile strength of around 80 ksi (550 MPa) and good elongation, providing excellent toughness and crack resistance. It offers remarkable resistance to oxidation, corrosion, and high-temperature scaling, making it perfect for welding dissimilar metals and operating in harsh environments.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCr-3 MIG and TIG Filler Welding Wire and Rod are commonly used for welding Inconel and Incoloy alloys, stainless steels, and dissimilar joints between nickel-based alloys and carbon or low alloy steels. They are particularly well-suited for applications in heat exchangers, chemical processing equipment, marine components, pressure vessels, and power plant systems where resistance to corrosion and high temperatures is essential. Additionally, this filler is utilized for overlay and cladding operations to improve surface properties.
