Elvis Nickel Alloys stands out as a top-notch manufacturer and supplier of Alloy C263 Sheets and Plates right here in Texas, particularly in Houston. We’ve built a solid reputation for providing high-quality products that cater to industries requiring materials with exceptional strength and corrosion resistance. Our Alloy C263 Sheets and Plates are meticulously crafted to meet rigorous international standards, serving sectors like aerospace, power generation, and chemical processing. With a strong focus on innovation, reliability, and customer satisfaction, we pride ourselves on delivering timely and cost-effective solutions to clients throughout Texas and beyond.
These Alloy C263 Sheets and Plates are made from a nickel-based superalloy that includes about 20% chromium, 20% cobalt, and 6% molybdenum, along with trace amounts of titanium and aluminum to boost precipitation hardening. They boast impressive tensile strength, excellent creep resistance at high temperatures, and good ductility. Known for their remarkable oxidation resistance and weldability, they’re perfect for demanding applications where strength and durability are crucial in high-temperature settings.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
You’ll find Alloy C263 Sheets and Plates widely used in aerospace components, gas turbines, combustion chambers, and other critical parts that need to withstand high temperatures and stress. They’re also essential in petrochemical processing equipment, heat exchangers, and furnace components that operate in harsh environments. Thanks to their outstanding fabricability and weldability, they’re ideal for complex assemblies and repair tasks. With their superior performance under thermal and mechanical stress, Alloy C263 sheets and plates play a vital role in sectors like energy, defense, and advanced industrial manufacturing.
Contact us to get a quick quote for your requirement.
Alloy C263 sheets and plates are widely used in high temperature corrosion resistance. Their excellent oxidation and creep resistance make them ideal for aerospace applications, including turbine blades, seals and exhaust systems. The compound is also used in the electrical industry for gas turbines and boilers, as well as in extreme cases contact equipment and chemical process plants Apart from that, C263 is used in marine applications the environment, heat exchangers and furnace components due to its durability, strength, and fatigue resistance of the heater occurs.
